Dispenser Light (select models)
A light activates within the dispenser area at full power
when dispensing ice or water with the main dispenser
pad. The light will also illuminate when using the
FrontFill™ Button (select models).
Dispenser Pad
The Dispenser Pad is located on the back wall of the
dispensing area. When the dispenser pad is pressed,
the selection chosen on the dispenser control panel
will dispense.
FrontFill™ Button (select models)
The FrontFill™ Button works independently of the
dispenser controls, providing an up-front alternative to
the dispenser pad for dispensing water. This feature is
convenient for filling large items that will not fit into
the dispenser area (i.e. sport bottles, pitchers, large
pans, coffee pots).
This feature allows added convenience of dispensing
ice and water simultaneously. To use, choose your
preferred ice mode from dispenser control panel. Press
container against dispenser pad while pressing the
Front Fill Button.
Removable Tray
The Removable Tray at the bottom of the dispenser
area is designed to collect small spills and may be
easily removed for cleaning and emptying purposes.
IMPORTANT: Removable tray does not drain. Do not
allow tray to overflow. If it does, remove tray and wipe
up overflow.
Water Dispenser Operation
To avoid personal injury or property damage,
observe the following:
• Do not put fingers, hands or any foreign object
into dispenser opening.
• Do not use sharp objects to break ice.
• Do not dispense ice directly into thin glass, fine
china or delicate crystal.
CAUTION
To Use Dispenser Pad:
• Choose water selection from dispenser control panel.
• Press sturdy, wide-mouthed container against
dispenser pad. When dispensing crushed ice, hold
container as close to chute as possible to reduce
spraying.
• Release pressure on dispenser pad to stop water
dispensing. A small amount of water may continue to
dispense and collect in dispenser tray. Large spills
should be wiped dry.
Note
• During initial use of water dispenser, there will be
a one- to two-minute delay while water tank fills
before water dispenses. Discard first 10-14 glasses
of water after initially connecting refrigerator to
household water supply and after extended
periods of nonuse.
Ice and Water
FrontFill™
Button
Dispenser Features
(select models)
Main
Dispenser
Pad
Removable
Tray
