Cleveland Range 36-CGM-300 Electric Steamer User Manual



Cleveland
P
roject ________________________________
Item __________________________________
Quantity _______________________________
F
CSI Section ____________________________
A
pproval _______________________________
D
ate __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Fax: 1-216-481-3782
Web Site: www.ClevelandRange.com
Email: Steam@ClevelandRange.com
CLASSIC CONVECTION STEAMERS
15 PSI BOILER BASE STYLE
MODELS: 36-CGM-300
Cleveland Standard Features
Cooking Capacity for up to six 12˝ x 20˝ x 2
1
2
˝ deep Cafeteria Pans.
Pressureless cooking with forced convection steam,
permitting doors to be opened while cooking continues.
Solid State Controls operate water level and safety func-
tions.
Each compartment is equipped with a 60 minute mechanical
timer, separate bypass switch for constant steaming and a
cold water condenser for superior cooking results.
Instant Steam Standby Mode: Holds generator at steaming
temperature. Allows unit to start cooking instantly.
Durable 14 Gauge Stainless Steel Construction:
For Compartment Door and Steam Cooking Cavity.
Separate Main Power Switch for “On/Off”
Exclusive Steam Cooking Distribution System: The
exclusive Convection Jets produce a high velocity
convection steam without fans. Coved Corner design in
cooking compartment distributes heat evenly and is easy to
keep clean. Creased top & bottom enhance drainage. Cold
Water Condenser for each compartment maintains a dry
steam. Fully insulated cooking compartment for thermal
efficiency. Removable Stainless Steel Slide Racks for easy
cleaning.
Exclusive “Cool to the Touch” Compartment Door
Design: Free floating inner door with reversible door gasket
provides an air tight seal. Stainless Steel Slam/Latch Door
Latch mechanism provides greater reliability.
Left Hand Door Hinging: Compartment Doors hinged left,
controls on the right.
Modular Cabinet Base with Hinged Door.
High Efficiency Gas Steam Generator with NickelGuard,
Electronic Spark Ignition and Automatic Water Fill on start up.
Automatic Generator Drain at shutdown: Contains a
“Water Jet” Spray Rinse Cleaning Cycle to keep drain clear.
Automatic Water Level Control System with Low Water
Power Cut-off Circuit.
Steam generator equipped with High Limit Pressure Safety
Switch, 15 psi Safety Valve, and Steam Generator Pressure
Gauge.
NSF Certified 6˝ Stainless Steel Legs with adjustable
flanged feet for a one inch level adjustment.
Gas Pressure Regulator and Control Valve.
Standard Voltage for Controls: 115 volts, 60 Hz, single phase.
All Controls are serviceable from the front.
Options & Accessories
Right Hand Door Hinging, Controls on the Left (DHR)
Shall be Two Compartments, CLEVELAND Convection Steamer, Model 36-
CGM- _____ , Gas-fired Steam Generator, NickelGuard, _____ M BTU. Solid
State Controls operate timing, water level and safety functions. Steam
Generator with Automatic Water Fill on start-up, Automatic Blowdown with
additional Manual Drain Valve and Electronic Spark Ignition. For each cook-
ing compartment: 60 minute Mechanical Timer, Manual Operation Mode and
Cold Water Condenser. Type 304 Stainless Steel cooking compartment.
Electronic Timer with Compensating Load Feature (ETC)
ON/OFF Steam Switch only for compartment controls (MC)
Cafeteria pans in depths of 1˝, 2
1
2˝, 4˝ and 6˝
Compartment Door Steam Shut Off Switch (SCS)
Power Take Off Kit (GPTO), Kettle Interconnecting Kit (IMK)
Stainless Steel Base Frame (FSS)
Stainless Steel Insulated Flue Cover (SSF)
Quick Disconnect for gas line (QDC)
Secondary Low Water Cut-Off, factory installed (CALG)
(Required for AZ. AR. CA. CO. CT. DE. FL. GA. HI. IL. IA. KS. MD. MA. MI.
MN. MT. NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY,
Wash. DC)
Correctional Packages
Boiler Descaling Pump Kit (107142)
Water Filters
Rear Gas Connection (RGT)
Short Form Specifications
Shown with optional
Electronic Timer
Cleveland Classic Series
TWO COMPARTMENT, PRESSURELESS
GAS FIRED STEAM GENERATOR, with NICKELGUARD™
200, 250, 300M BTU, 36” WIDE CABINET BASE DESIGN
CONVECTION
STEAMERS
1
0
0
%
5
Y
e
a
r
B
o
i
l
e
r
W
a
r
r
a
n
t
y
N
i
c
k
e
l
G
u
a
r
d
SECT. III PAGE 11
1007
