Before yoU Call for serviCe
Problem may be caused by What to do
Small particles deposited on
items (cont.)
Incorrect detergent use Use only correct amount of dishwasher detergent according
to water hardness (see page xx) and the wash program
selected. Fill dispenser only when ready to start the
dishwasher. Do not use old or caked detergent. Store
dishwasher detergent in dry place and in a closed container.
Change the dishwasher detergent if results are still poor.
Filter system Make sure filter system is clean and properly installed.
Low water pressure Check that water valve is fully open. Make sure water
pressure is between 20 and 120psi and flow rate is 1.0 gpm
minimum.
Water not hot enough Check hot water supply temperature. Minimum
recommended incoming temperature to the dishwasher is
120ºF.
Items not loaded properly or
overloaded
Make sure dishwasher is loaded according to instructions
(see page xx). Do not overload. Make sure spray can reach
all soiled surfaces.
Incorrect wash cycle selected Select a wash cycle with a longer wash time.
Hard water See “Hard water” under Spotting and filming on page xx.
Detergent left in detergent
compartment
Detergent dispenser lid not
opening
The lid may not be opening. Check for items blocking it.
Old detergent Do not use detergent that is hard or caked in the box. Use
only fresh detergent. Add detergent to dishwasher just
before starting it.
Spray arms do not rotate properly Make sure that both spray arms rotate freely. Make sure that
items do not obstruct movement of spray arms. If necessary,
clear any obstructions. Make sure top rack is pushed in all
the way so that spray arm on rack connects to nozzle on
back wall.
Make sure holes in spray arms are not blocked. If
necessary, clear holes with a pointed object and rinse under
water.
Cycle not complete Close door, wait for cycle to complete.
Chipping or breaking of
glassware
Improper loading Do not overload. Load between rack prongs, not over them.
Glasses loaded over prongs will not be supported and may
chip or break. Always use the top rack for delicate items.
Dacor recommends that you wash fine china and crystal by
hand.
Unusual noise Improper loading Utensils may not be secure or something small may have
dropped from the rack. Water may cause utensils to rattle.
Make sure dishware is secure.
Water in bottom of dishwasher
tub near filters.
Dishwashing cycle not complete Close door. Allow cycle to finish.
Some water in strainer is normal Some water in strainer portion of filter at end of cycle is
normal.
See “Dishwasher does not drain
Properly” below
Dishwasher does not drain
Properly
Air gap plugged Be sure the air gap is not blocked or plugged. The air gap
is a vent located on top of the sink. It is connected to the
dishwasher. It is required by some local codes.
Drain hose kinked Check drain hoses. Make sure they are not kinked.
Filter(s) clogged Check and clean filter(s) if necessary. See page xx.
