the parts of yoUr Dishwasher
Control Panel Located on top of the door. The lighted buttons control your dishwasher. See page xx for
a description of the button functions. The display tells you important operating informa-
tion. See page xx for a description of the symbols that appear on the display.
Detergent Dispenser Automatically releases the soap during the wash part of the cycle (see page xx).
Dishwashing Tub The compartment where tableware and cookware are loaded for washing.
Door Switch Located in the door. Automatically pauses dishwashing when the door is opened.
Filter System Traps food and debris that could damage or plug up the mechanical parts of your dish-
washer. See page xx for cleaning instructions.
Racks The racks are coated with a durable coating that protects the finish of the loaded table-
ware and cookware. They have fold down tines and shelves to allow you to load various
size dishes and flatware (see page xx).
Rinse Aid Dispenser Automatically releases rinse aid during the rinse part of the cycle. Rinse aid is a fluid
that helps the dishes dry properly and helps prevent water spots. The amount of rinse
aid dispensed is adjustable (see page xx).
Silverware Basket Use the silverware basket to hold silverware and kitchen utensils. It has 2 compartments
that snap closed to hold small items (see page xx).
Spray Arms The spray arms spray water on the dishes at high pressure to remove soil.
Toe Kick Panel Covers the internal mechanics of the dishwasher. It is located behind the bottom of the-
door. It must always be in place during operation.
GettinG to Know yoUr Dishwasher
