Green&Clean Hood Type Dishwasher,
Manual with ZERO LIME Device &
CLEAR BLUE System
ITEM #
MODEL #
NAME #
SIS #
AIA #
Short Form Specification
Item No.
APPROVAL:
Electrolux Professional, Inc.
www.electroluxusa.com/professional
10200 David Taylor Drive, Charlotte, NC 28262 • Telephone Number: 866-449-4200 • Fax Number: 704-547-7401
Warewashing
Green&Clean Hood Type Dishwasher, Manual with ZERO LIME
Device & CLEAR BLUE System
Warewashing
Green&Clean Hood Type Dishwasher,
Manual with ZERO LIME Device & CLEAR
BLUE System
504262
(EHT8ILG4)
Green & Clean Hood Type Dishwasher,
Manual double skin hood with ZERO LIME
Device, CLEAR BLUE Filtering System,
Detergent and Rinse aid pumps, 80racks/hour
- 240 V/3/60 Hz
504263
(EHT8ILG8)
Green & Clean Hood Type Dishwasher,
Manual double skin hood with ZERO LIME
Device, CLEAR BLUE Filtering System,
Detergent and Rinse aid pumps, 80racks/hour
- 208 V/3/60 Hz
Unit to be Electrolux Green & Clean EHT hot water sanitizing dishwasher with WASH
SAFE CONTROL. Electrical characteristics to be 240 volts or 208 volts, three phase
operation. Energy Star 2.0 ceritified product. Unit to feature atmospheric built-in booster
system with built-in rinse booster pump thus guaranteeing rinse pressure during rinse
cycle. Maximum water consuption of 1/2 gal (2 L) per rack. Washing performance is
guaranteed by a powerful 1.1 HP (0.8 kW) wash pump and upper and lower stainless
steel revolving washing spray arms. Features ZERO LIME Device to automatically de-
scale the whole hydraulic circuit and washing chamber. Features "WASH SAFE CONTROL"
led light. Green light will indicate that all items washed have been properly rinsed. CLEAR
BLUE filtering to system remove majority of soil from the wash water. 304 Stainless
steel construction to include double skin insulated hood, external, front and side panels,
wash tank, tank filter plus wash and rinse arms. Field convertible from straight to corner
operation. Includes drain pump, detergent and rinse aid pumps and is equipped with
flexible fill hoses. Delivered on height-adjustable feet. Covered by Electrolux Platinum
Star Service Program two-year parts and one-year labor warranty, installation start-
up and performance check-up after one year from installation.
Main Features
• ZERO LIME Device ensures total scale removal from the hydraulic
circuits and the washing chamber allowing for lower energy
consumption thanks to the high-efficiency of the heating elements.
• CLEAR BLUE advanced filtering system provides cleaner wash
water and higher active detergent thus ensuring better washing
performances and lower running costs.
• Requires only 1/2 gal (2 L) of water per rack thus ensuring low
energy, water, detergent and rinse aid consumption.
• Energy Star 2.0 certified product.
• Built-in atmospheric booster sized to raise incoming cold water to
a minimum of 180°F (82°C) for sanitizing rinse. No external booster
is required. Constant temperature above 180°F (82°C) throughout
the rinsing cycle.
• ETL C & US and ETL-Sanitation approved (ANSI/NSF 3 sanitation
standard).
• Green light of "WASH SAFE CONTROL" confirms that items have
been rinsed properly.
• Unique temperature interlock guarantees required temperatures in
both the wash and final rinse.
• Maximum capacity per hour of 63 racks or 1.134 dishes (ETL-S
mode) easy to switch to 80 racks or 1.440 dishes (High
productivity) by just pressing a button.
• 57/84/150 seconds cycles (ETL-S mode).
• 45/84/150 seconds cycles (High Productivity mode).
• Incorporated Soft Start feature to offer additional protection to more
delicate items.
• Slanted wash arms and sloped ceiling to avoid detergent-filled wash
water dropping on clean dishes after the rinsing phase, thus
guaranteeing ideal washing results.
• Cycle may be interrupted at any time by lifting the hood.
• Automatic self-cleaning cycle and self-draining wash pump and
booster to avoid bacteria proliferation.
• State-of-the-art electronic controls with built-in programming, self-
diagnostics for serviceability and automatic interior rinse-down
cycle.
• Built-in rinse aid and detergent pumps with automatic initial and
continuous cycle loading for perfect result while minimizing service
and maintenance needs.
• Three phase electrical connection.
• Deep drawn pressed 6.4 gal (24 L) tank in front position with no
welded points offer a guaranteed water tight solution and eliminates
dirt traps.
• Vertical self-draining wash pump ensures no bacteria proliferation
and bad smells during non-operation hours.
• Booster highly resistant to chlorinated water thanks to robotised
TIG welding technology.
Construction
• Heavy duty Stainless steel construction. Internal cavity as well as
exterior panels are in 304 series Stainless steel.
• Double skin insulated hood.
• Specially designed Stainless steel wash/rinse arms and nozzles
provide superior cleaning action.
• Revolving interchangeable Stainless steel wash/rinse arms above
and below the rack, screw out for simple clean up.
