584105 (WGGRAFQOOO) S90 2 Open Gas Burners
(34,000 BTU), open base,
c-board, 1 side operation
Item No. ___________________________________
Unit to be Electrolux S90 Heavy Duty two 34,000 BTU (10 kW) burner
gas range on open base. High efficiency burners with continuous
power regulations from 7,500 BTU (2.2 kW) “simmering” to high
power of 34,000 BTU’s (10 kW). Thermocouples as standard on
burners for added safety. Unit to have raised rear c-board for against
the wall or back to back unit installation. Body and open base of unit
entirely in 304 stainless steel. Pan supports in heavy duty cast
iron. Unit shall have heavy duty 304 stainless steel internal frame
with reinforcement on the top of 0.157″ (4 mm). Extra strength
work top in heavy duty 0.118″ (3 mm) stainless steel. “Lastertec”
connection system permits units to be connected to each other
creating a seamless work top.
Covered by Electrolux Platinum Star® Service Program two-year
parts and one-year labor warranty, installation start-up and
performance check-up after one year from installation.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME #______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
Modular Cooking Range Line
S90 Heavy Duty 2-Burner Gas
Range on Open Base C-Board
Main features
• The two 2″ (50 mm) diameter 34,000 BTU (10 kW) high efficiency
burners suit high performing cooking requirements for the most
demanding customers.
• Manual gas valves with fixed high and low positions allow precise
control of the flame intensity. Simmering as low as 7,500 BTU’s (2.2 kW).
• Large sized pan support in cast iron (stainless steel as option) with long
center fins to allow the use of the largest down to the smallest pans.
• Open base compartment for storage of pots, pans sheet pans etc.
• Flat deep drawn spillage area with cleaning openings on front and rear
side, with removable pan supports, burner rings and flame ignition parts.
• Heavy duty internal frame 304 type stainless steel with reinforcement on
top of 0.157″ (4 mm).
• 0.118″ (3 mm) top in 305 type stainless steel.
• “Lasertec connection system” creates seamless work top when units are
connected to each other.
• Raised rear c-board permits unit to be connected up against the wall for
better hygiene.
• Unit delivered with four 7-7/8″ (200 mm) legs as standard (all round
stainless steel plinth as option).
Optional Accessories
• Set 4 castors (2 with brake).
•2.3″ (60 mm) diameter burners with power regulation from 5,000 BTU
(1.5 kW) to 20,500 BTU (6 kW).
• Simmering plate.
• Left side stainless steel 0.118″ (3 mm) panel.
• Right side stainless steel 0.118″ (3 mm) panel.
•5″ (130 mm) portioning shelf.
•7.8″ (200 mm) portioning shelf.
• All round stainless steel kick plates.
• Shelf for open base.
• Shelf fixation kit for open base.
Modular Cooking Range Line
S90 Heavy Duty 2-Burner Gas Range on Open Base C-Board
Modular Cooking Range Line
S90 Heavy Duty 2-Burner Gas Range
on Open Base C-Board
