Approval: ___________________________________________
726678 (RH06FE2HU) 23 ft
3
Full Size Freezer
1 split door 115 V/1p/60Hz
727019 (RH06FE2HRU) 23 ft
3
Full Size Freezer
1 split door 115 V/1p/60Hz
remote version
Item No. ___________________________________
The Electrolux range of refrigerated cabinets are built with
external and internal AISI 304 stainless steel. High-density
expanded polyurethane insulating foam, 3″ (75 mm) in thick-
ness. Full door with lock and microswitch to switch off the fan
when the door is opened. Built-in refrigeration unit; ventilated
operating mode; SMART Electronic Control equipped
with: history (HACCP) for critical high temperature, alarm
service, full diagnostic, remote control via modem; electronic
defrost only when required; defrost outlet pipe; external digital
temperature display. Humidity level adjustment. Internal
lighting. Cavity drain. For ambient temperatures up to 110 °F
(43 °C). CFC and HCFC free. R134a gas in refrigeration
circuit. Gas in foam: cyclopentane. Energy Star certification
for energy savings. Supplied with n. 4 x 2/1GN Rilsan® coated
grids and n. 4 sets of 2 stainless steel grid runners.
Covered by Electrolux Platinum Star
®
Service Program two-
year parts and one-year labor warranty, installation start-up
and performance check-up after one year from installation.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME #______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
Refrigeration
SMART 1 Split Door Freezer
(23 FT
3
)
Main features
EASY TO INSTALL
• Mounted on adjustable stainless steel feet, with castors as an option.
• Choice of doors to suit varying kitchen requirements.
• Freezer models have operating temperatures that can be adjusted from 5 °F
to -11 °F (-15 to -24 °C) to suit both meat and dairy storage requirements.
• Performance guaranteed at ambient temperatures of 110 °F (43 °C).
EASY TO CLEAN
• Forced air circulation for rapid cool down and even temperature uniformity.
• Constructed from the highest quality AISI 304 stainless steel.
• Interior base with corners, pressed from a single sheet.
• Sides and back of the 1-door models are formed from a single sheet of
stainless steel to avoid dirt traps.
• Evaporator unit is placed outside the cell to provide the maximum storage
capacity.
• Refrigerators are fitted with outlet pipe.
EASY TO USE
• Accommodates GN 2/1 containers or shelves on anti-tilt runners.
• External digital temperature display.
• Interior light and lockable door.
• SMART electronic control gives the following benefits:
• HACCP: when temperature exceeds critical limits, an acoustic and visual
alarm are activated. All events are recorded displaying date and time of all
events.
• SMART defrost: the defrost cycle is activated only when necessary thanks to
the four-probe control and a patented algorithm for ice detection.
• Intelligence when failure: when a probe breaks it remembers its perfor-
mance of last 24 hours and continue to work. In this way food is safe and
service can be called.
• Diagnostic: four probes constantly control working condition of the
appliances.
• Food categories: depending by food stored it can be selected appropriate
temperature and humidity just pushing a button.
EASY TO MAINTAIN
• Heavy-duty construction that avoids use of any plastic parts.
• The cooling unit (compressor, condenser and evaporator) can be removed
with a single operation from either the top or back.
• Evaporator cover is easily removable for service.
• Fault indication from the smart control.
EASY ON THE ENVIRONMENT
• SMART electronics defrost only when required to save energy.
• Cabinet fitted with up to 3 ″ (75 mm) thickness of cyclopentane insulation
for best insulating performance. CFC and HCFC-free insulation.
• Refrigerant type: R134a or R404a.
Accessories
• Pair of stainless steel runners for
23 and 50 ft
3
SMART refrigerators 4
• Rilsan® coated full-size sheet grid 4
Optional Accessories
• Basic HACCP Printer (PNC 880048)
• 4 wheels (2 with brake) (PNC 880121)
• Pair of stainless steel runners for
23 and 50 ft
3
SMART refrigerators (PNC 880175)
• Rilsan
®
coated full-size sheet grid (PNC 880176)
• Pedal opening for 23 ft
3
SMART refrigerators (PNC 881458)
Refrigeration
SMART 1 Split Door Freezer (23 FT
3
)
Refrigeration
SMART 1 Split Door Freezer (23 FT
3
)
