Electrolux AOFP061CU4 Freezer User Manual



Approval: ___________________________________________
air-o-chill
®
Blast Chiller-Freezer 61 (66 lbs.)
726973 (AOFP061CU4) Blast Chiller-Freezer 61 (66 lbs.)
240 V/3p/60Hz -12A
726974 (AOFP061CTU4) Blast Chiller-Freezer 61 (66 lbs.)
240 V/3p/60Hz -12A
(Tower configuration)
Item No. ___________________________________
Unit to be Electrolux air-o-chill
®
Blast Chiller-Freezer 61. Chilling load
capacity to be 66 lbs. (30 kg) from 160 °F to 39 °F in 90’, freezing load
capacity to be 55 lbs. (25 kg) from 160 °F to 0 °F in max 240’ on up to
6 Steam table pans. Unit shall feature Micro-processor controlled
Soft-chilling, Hard-chilling and Blastfreezing cycles. At the end of each
Blast-chilling- or freezing cycle the unit shall automatically activate a
holding cycle. Defrost cycle is automatically and intelligently activated:
ice build up on evaporator is automatically detected and defrost
activated to maximize performance efficiency. Manual activation of
defrost cycle is possible. Unit does not have any heat limitation and can
accept food directly from oven at cooking temperature. The unit features
both time and core temperature controlled chilling cycles. One core
temperature probe is provided as standard, up to three are available.
All 304 stainless steel construction. Self contained 1.5 HP air-cooled
compressor.
High density CFC and HCFC cyclopentane insulation material.
EKIS, pc-controlled HACCP monitoring software package available at
additional cost.
Half day chef training included.
Covered by Electrolux Platinum Star® Service Program two-year parts
and one-year labor warranty, installation start-up and performance check-
up after one year from installation.
Short Form Specification
Electrolux Professional, Inc.
www.electroluxusa.com/professional
3225 SW 42nd Street, Fort Lauderdale, Florida, 33312 • Telephone Number: 866-449-4200 • Fax Number: 954-327-6789
ITEM # _______________________________________________
MODEL # _____________________________________________
PROJECT NAME #______________________________________
SIS # _________________________________________________
AIA # _________________________________________________
air-o-chill
®
Blast Chiller-Freezer 61 (66 lbs.)
Main features
Load capacity: 66 lbs (30 kg) in chilling; 55 lbs. (25 kg) in freezing.
Will chill product from 160° F to 39° F or below in less than 90 minutes.
Will freeze product from 160° F to 0° F or below in less than 240 minutes.
Easy-to-use, electronic control panel. Fully programmable.
Time or (automatic) core temperature controlled operation.
Cruise control (PATENT PENDING): self-adjusting probe-driven chilling.
Soft chill, Hard Chill and Blast Freeze modes.
Auto hold at temperature reached at end of blast chilling or freezing cycle.
Turbo cooling: non-stop mode (working temperature: from 39 to -32° F).
Pre-programmed ice cream hardening cycles.
Standard equipped with one core temperature probe, can be ordered either with
up to three core temperature probes or with one 3-sensor probe.
Automatic Intelligent and manual defrost modes.
Display: large LED for temperature and time/core temperature read out.
Audible alarms and visual indicators for food safety (HACCP) issues and
separate audible and visual for unit malfunctions.
During cycle, temperature and time is monitored
EKIS software (pc-based HACCP monitoring) requires optional board
On-board HACCP monitoring capable.
Electrolux Platinum Star® Service package included:
2-year parts, 1-year labor warranty, 5-year compressor warranty.
Start-up install check.
Equipment check-up after 12 month from installation.
Half day chef training session
Construction
Magnetic, easy-to-remove heated gaskets.
Standard equipped with 6, adjustable legs, castors available as option
All 304 stainless steel construction.
Seamless hygienic chilling chamber with all rounded corners for easy cleaning.
Coated evaporator fins.
Swing hinged front panel for easy service access to main components.
Self contained 1.5 HP compressor
R404 A refrigerant
Included Accessories:
Three 304 stainless steel grids (12× 20) PNC 922062
Installation Accessories:
1 single sensor probe for air-o-chill® PNC 880089
2 single sensor probe for air-o-chill® PNC 880096
One 3 sensor probe for air-o-chill® PNC 880088
Electronic board for HACCP through PC Network PNC 860183
Stacking kit for tower execution with air-o-chill® 61 PNC 881011
Optional Accessories:
Single 304 stainless steel grid (12× 20) PNC 922062
Single 304 stainless steel full-size grid (21× 26) PNC 922076
air-o-chill
®
Blast Chiller-Freezer 61 (66 lbs.)
