Filter
Top Products
BENEFITS
APPLICATION/SIZING
INSTALLATION TIPS
OPERATION TIPS
CB20-124E Water Filter
High flow, high capacity carbon filter for chlorine and chloramine
reduction
CB20-124E System: EV9100-51
124 Replacement Cartridge Kit:
EV9105-02
Kit contains: (1) CC1E replacement cartridge
CB20-124E System: EV9100-51
124 Replacement Cartridge Kit:
EV9105-02
Kit contains: (1) CC1E replacement cartridge
Improves the taste and consistency of beverages
and ice by reducing chloramine, chlorine and
other off-tastes and odors
CC1E extended service cartridge contains radial
flow granular activated carbon (GAC)
High pressure housing includes head with
pressure relief valve, mounting bracket and bowl
Integral outlet pressure gauge monitors operation
Easily plumbs to existing filtration systems to add
chloramine reduction capability
Complete modular package lets you expand
capacity as needed
Choose a mounting location which is suitable to
support the full weight of the system when
operating (30 lbs.)
3/4" FNPT inlet and outlet connection
Install on cold water lines only
Do not install where unit is exposed to direct
sunlight
Allow a minimum of 4" clearance under the filter
to facilitate cartridge change
Do not braze/solder fittings into head
Never use a saddle valve for connection
Change cartridge on a regular 6 month
preventative maintenance program
Change cartridge when capacity is reached (15,000
gallons) or when flow becomes too slow
Change cartridge when the difference between the
inlet pressure and the system outlet gauge is
greater than or equal to 20 psi
Service flow rate must not exceed 5.0 gpm
Always flush the filter cartridge to drain for
fifteen minutes at time of installation and
cartridge change
For high flow, high volume foodservice
applications requiring chloramine reduction
Rated Capacity: 15,000 gallons (56,775L)
Up to 5 gpm (19 Lpm) flow rate
For coffee and ice applications, add scale
reduction feeder at outlet of system. Part no.
EV9798-45
EV9100-51
