Star Fire Sentry Series 60"
Gas Restaurant Range
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
Star Fire Sentry Series 60" Gas Restaurant Range
Models:
S284 S284E ST284 ST284E
Specifications:
Gas medium duty range with two full-size ovens, 60"
(1524mm) wide, (10) open top burners with extra heavy
duty cast iron tops and ring grates. Stainless steel 10"
(254mm) high backguard with slotted black enameled cap.
Available with optional hot top(s) and/or griddle. Available
with convection base oven(s).
Standard Features:
Flame failure and spark ignition
on all concealed burners
Cast iron tops and ring grates
Stainless steel exterior
Ten, 24,000 BTU/7.03 kW (Nat) or
20,000 BTU/5.86 kW (Pro) Starfire
burners
30,000 BTU/8.79 kW race track
even heat oven burner
Heavy duty “FDO” oven ther-
mostat accurate to ±10°F (±5°C)
temperature range 150°-500°
(66°C-260°C)
Two standard ovens; fully porce-
lain interior; including top, bot-
tom, sides, back and door liner.
Nickel plated oven rack (one per
oven) on 4-position removable
rack guides
10" (254mm) high stainless steel
back guard with slotted black
enameled angled cap
6" (152mm) high stainless steel
legs - adjustable
Sentry safety protection on con-
cealed burners only, prefix S
Sentry safety protection to open
burners prefix ST
Electronic spark ignition, mod-
els with suffix E. requires single
phase 115v, 60H, 240v, 50Hz elec-
trical connection
Gas Regulator
One year limited warranty on
parts & labor(USA & Canada only)
Optional Features:
Convection oven base: for (1) CO
base, add suffix RC, CO is on the
left side in CO-standard oven
combination; for (2) CO bases,
add suffix RC2, for E models add
before suffix E; ie ST284RCE
Heavy duty 5/8" (16mm) griddle
plates available in the following
widths - 12", 24", 36" & 48" stan-
dard on RHS, optional on LHS
Hot tops 3/8" (10mm) thick - stan-
dard on LHS, optional on RHS
Additional oven rack
Stainless steel two piece back-
guard and plate shelf
17" (432mm) high stainless steel
backguard
Stainless steel main back
6" (152mm) stainless steel legs
Casters
Model # ST284
NOTE: Ranges supplied with casters must
be installed with an approved restraining
device.
®
NOTE: CE certification applies only to ST models
