Revised 7/97
Monogram.
™
U
L
R
Listed by
Underwriters
Laboratories
For answers to your GE Monogram,
™
GE Profile,
™
GE, Hotpoint and RCA appliance questions, call
GE Answer Center
®
service, 800.626.2000.
ZDP36L4DWSS—36" Professional Ranges
Dimensions and Specifications (in inches)
These ranges are factory set for either natural gas or
liquid propane gas.
36" Natural Gas Model:
ZDP36N4DWSS–4 gas burners and griddle
36" Liquid Propane Gas Model:
ZDP36L4DWSS–4 gas burners and griddle
Accessory Requirements:
All models require the installation of a backguard. A
backguard should be ordered at the same time as the
range. Both must be on site at the time of installation.
Order one backguard for 36" models:
ZX1B36WSS–1-1/2" high backguard
(required for island installations)
ZX12B36WSS–12" high backguard
ZX22B36WSS–22" high backguard with warming rack
(2 piece)
Advance Planning:
Refer to dimensional drawings for appropriate placement
and necessary clearances when planning
the installation.
• Cabinetry cannot be installed directly above the range.
• This range requires the installation of a vent hood,
30" to 36" above the surface.
– The vent hood must be at least 24" deep.
– The vent hood must be the same width as the range.
– The vent hood must provide at least 600 CFM and
up to 800 CFM.
– When installing a range that includes a grill, select a
blower on the high end of the CFM recommendation.
• Working areas adjacent to the range should have
18" minimum clearance between countertop and
cabinet bottom.
• Clearance between range and side wall or combustible
material must be at least 12" on each side.
21-1/4"
12"
1-1/2"
35-1/4"-36-3/4"
28-1/4"
35-7/8"
Available Backguards
ZX22B36WSS
ZX12B36WSS
ZX1B36WSS
