Monogram.
“
Specification Revised 4/05
110154
Monogram.
“
ZIFS36NM – GE Monogram 36" Built-In Stainless Steel All-Freezer
Enclosure Cutout and Product Dimensions (in inches)
ZIFS36NMRH, Freezer
Handle on the left side, the door swings left to right.
ZIFS36NMLH, Freezer
Handle on the right side, the door swings right to left.
461Dia27
10-3/4" Max.
10" Min.
24-3/4"
35" Case
36" Overall
84-1/2" Max.
83-1/2" Min.
4"
73-1/2"
26-3/4"
For answers to your Monogram,
®
GE Profile
™
or
GE appliance questions, visit our website at
GEAppliances.com or call
GE Answer Center
®
service, 800.626.2000.
R
Listed by
Underwriters
Laboratories
Refrigerators are much heavier at the top than
at the bottom – be extra careful when moving.
Caution
• To achieve a flush fit, the finished cutout width must be
at least 36" wide.
• In a semi-flush installation, the finished cutout must
be 35-1/2".
• The electrical and water locations must be located as
shown for either type of installation.
*Shipped at 84" installation height. Can be adjusted
to 83-1/2" or 84-1/2" with Grille Panel Kits.
*36" for a flush installation.
35-1/2" Min. for a semi-flush installation.
Note: Additional cutout width may be required when side
panels are used. Add side panel thickness to the finished
cutout to calculate rough-in width. See installation
examples on the following page.
36" Frame to Frame
84*
26-3/4"
Including
Tubular
Handles
35"
Case
Width
24-3/4"
Case
Depth
75" From Floor
to Bottom
of Electrical
Area
84-1/2" max
83-1/2" min
Finished
Opening
*Finished Width
Electrical
Area
5
5
3-1/2
24-3/4" Total
Depth
Water Supply
3-1/2
Wall View
2-1/2
5
6
36" Frame to Frame
84*
26-3/4"
Including
Tubular
Handles
35"
Case
Width
24-3/4"
Case
Depth
75" From Floo
r
to Bottom
of Electrical
Area
84-1/2" max
83-1/2" min
Finished
Opening
*Finished Width
Electrical
Area
5
5
3-1/2
24-3/4" Total
Depth
Water Supply
3-1/2
Wall View
2-1/2
5
6
