Hotpoint 6BCR Refrigerator User Manual



Specification Created 1/10
410398
HTH18GBT – Hotpoint
®
ENERGY STAR
®
18.2 Cu. Ft. Top-Freezer Refrigerator
Front View Top View
A
G
E
C
F
'94 TMNF Refer
B
D
H
Note: Before installing, consult installation instructions packed with product
for current dimensional data.
Note: All Top-Freezer No-Frost Right-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your left and the
hinges are on your right.
All Top-Freezer No-Frost Left-Hand Refrigerator Doors: As you
face the front of the refrigerator, the handle is on your right and the
hinges are on your left.
Height to top of hinge (in.) A 67-3/8
Height to top of case (in.) B 66-7/8
Height to mid-freezer (in.) 57
Case depth without door (in.) C 26-3/4
Case depth less door handle (in.) D 30-1/2
Case depth with door handle (in.) E 32-3/8
Depth with fresh food door open 90° (in.) F 56-3/8
Width (in.) G 28
Width with door open 90° with door handle (in.) H 30-3/4
Each side (in.) 3/4
Top (in.) 1
Back (in.) 1
Air Overall
Clearances Dimensions
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
Listed by
Underwriters
Laboratories
As an ENERGY STAR
®
partner, GE has determined
that this product meets the
ENERGY STAR guidelines
for energy efficiency.
