92254
Revised: October 8, 2001
Rev E
April 1998
EIMI Cornelius Inc; 1998
IMI CORNELIUS INC.
One Cornelius Place
Anoka. MN 55303-6234
Telephone (800) 238–3600
Facsimile (763) 422–3246
FOR
KIT PART NUMBERS 08027 AND 08030
FOR MODEL ED300 DISPENSER AND THE FOLLOWING 30” WIDE ICEMAKER MODEL
SERIES:
MANITOWOC QQ1400C, Q–DUAL
SCOTSMAN CME 806/865/1002/1056
Table 1. Loose-Shipped Parts
Item
No. Part No. Name Qty.
1 29505 Lid Assembly 1
2 22127 Icemaker Mounting Bracket 2
3 50904 RTV. 3Oz Tube 1
4
52946 Manual Ice Fill Cover – Black (08027) 1
52964 Manual Ice Fill Cover – Gray (08030)
5 91957 Label, “Disconnect Power Before Cleaning” 1
6 620042919 ED300 Ice Baffle 1
7 620701601 #10 x 1/2” LG. Sheetmetal Screw 12
8 620701902 #8–32 Nylon Acorn Nut 4
9 620701901 Sealing Washer 4
10 620701903 #8 Nylon Washer 4
11 92254 Installation Instructions 1
WARNING: The dispenser must be secured with 3/8–16 bolts (6) to the counter before
installing this icemaker adapter kit. Refer to the installation manual and figure 2 for the
counter mounting template.
CAUTION: Disconnect electrical power to the dispenser before proceeding with this
installation.
NOTE: Adjust the automatic agitation timer located in the dispenser’s electrical control box to 5 sec-
onds on, 20 minutes off. Access to the timer is provided by removing the merchandiser/upper front
panel.
1. Remove the top plastic bin covers (2) from the dispenser
