ED/DF175 22” CCM322/522 Nordic Style Lid Kit Installation Instructions
© 2007, IMI Cornelius Inc. - 1 - Publication Number: 620204721INS
INSTALLATION INSTRUCTIONS
ED/DF175 22” CCM322/522 NORDIC BLACK/GRAY STYLE LID KITS
This Nordic style kit applies to the Cornelius 22” wide CCM322/522 ice maker.
CAUTION: Disconnect electrical power to the dispenser before proceeding with the icemaker
adapter kit installation.
WARNING: The dispenser must be secured with 3/8-16 bolts (6) to the counter before installing
this Icemaker Adapter Kit. Refer to the installation manual and Figure 2 for the counter mounting
template.
1. Unpack Kit.
2. Insert baffle assembly into the adapter lid.
3. Place (2) sealing washers (item 9) over studs and (2) flat washers (item 11), then fasten in place
with (2) plastic acorn nuts (item 8).
4. Set ice maker lid on the top of the dispenser.
5. Using the slotted holes in the lid as a template, drill four (4) .140_ diameter (9/64_) holes at the
bottom of the slots (see detail A). Use extreme care not to drill into the hopper. Fasten the lid to the
dispenser with four (4) #8 sheet metal screws, two on each side.
6. Seal the ice maker to the top of the dispenser as follows:
A. Run beads of RTV around the opening in the lid and inside of the perimeter of the ice maker
outline so that the ice maker will set on the RTV.
B. Set the ice maker onto the lid and position it as required.
C. Wipe away the excess RTV.
7. Drill 9/64” diameter holes into the ice maker cabinet using the bracket as a template. Use extreme
care not to drill into any ice maker components (condenser, tubing, etc.). Secure the brackets using
the screws provided.
8. Install the wire form bracket, supplied with the bin stat kit (item 4), through the 5/8” diameter hole in
the bottom of the ice maker. Wrap the eye of the wireform over the stud near the hole to the end of
the wireform bracket and wrap the tube around the end of the bracket several times, insuring the
tube is secure.
NOTE: The bin stat must not interfere with the agitator rotation or in the path of ice falling from
the icemaker. If it interferes with the agitator or in the path of ice, bend the bracket out of the way.
Item
No.
Part No. Name Qty.
1 620043511
620043512
Cover, Gray
Cover, Black
1
2 620046011 Lid Assembly 1
3 22127 Bracket 2
4 70217 #8 Screw 12
5 50904 RTV 1
6 90221 Label 1
7 620204721INS Installation Instruction 1
8 620701902 Acorn Nut, 8–32 Nylon 2
9 620701901 Sealing Washer 2
10 620037007 Ice Baffle ED150 1
11 621701903 #8 Nylon Washer 2
12 630500109 Bin Stat 1
Release Date: October 5, 2007 www.cornelius.com Revision: A
