Installation Instructions
VS Series vented enclosures combine KICKER’s award-winning Solo-Baric
subwoofers with computer designed and human-fine-tuned enclosures.
They offer a level of bass performance never before thought possible from
a commercially available enclosure. The VS Series enclosures are covered in a
Caataalyzed PPolyurethaane
for protection and pre-loaded with either a Solo-
Baric
SL5
or
SL7
woofer.
The location and orientation of your VS enclosure will affect the quality
and quantity of the bass. Designed for use in SUVs and sedan type vehicles,
the enclosure offers you several mounting options.
The first rule you must remember is that the vent opening in these enclo-
sures cannot be obstructed. Around the tuning frequency of the vent a
substantial amount of bass is created. Therefore we recommend you leave
at least four inches of clear space around the vent.
If the enclosure is to be mounted all the way in the back of the vehicle, it
works best to point the woofer toward the front of the vehicle. Conversely,
if the enclosure is going to be mounted closer to the back seat, pointing the
woofer toward the rear of the vehicle will give you the best results. These
guidelines are good for when the enclosure is mounted cross-ways in the
vehicle as shown below.
VS8L5/ VS8L7/ VS10L5/ VS10L7/
VS12L5/ VS12L7
Vented Enclosure Systems
Front Mounting, woofer faces the back of the car!
Rear Mounting, woofer faces the front of the car!
AT LEAST
4"
AT LEAST
4"
FRONT
Congratulations! You have just purchased one of the most advanced
subwoofers in the history of car audio. Your KICKER Solo-Baric is the latest
in KICKER s trend-setting Solo-Baric line, designed and engineered to
deliver the ultimate in low bass performance and unmatched durability.
Thanks for buying KICKER. Enjoy.
