Technical data sheet for
ELECTRIC GRIDDLE 600mm
EP514-B, EP514-CB, EP514-LS
Heavy-duty thermostatic electric griddle
20mm thick griddle plate
Ribbed plate options
Mirror chromed plate options
Top weld sealed plates
7.2kW heating elements
2 models of base unit
Rear rollers
Stainless steel exterior
Easy clean
Easy service
Fully modular
Overall Construction
Griddle
• 20mm thick machined top plates standard
• Optional ribbed plate sections
• Optional mirror finish hard chrome plates
• 2.5mm thick 304 stainless steel splash guards sides and rear
• 2.5mm thick grease channel
• Single temperature control zone
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Side panels 1.2mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Vitreous enamelled control panel
• Stainless steel grease drawer
• Overlapping finish at front and rear of plate for easy clean
Bench mount (supplied as –B model)
• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs
with adjustable feet.
• Adjustable height 80mm – 105mm
Cabinet base (supplied as –CB model)
• Fully modular for match suite finish
• Double skin 0.9mm 304 stainless steel interior and exterior
• Optional GN 1/1 4 position racking kit
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with two
adjustable feet at front and two rollers at rear
Leg stand (supplied as –LS model)
• Fully modular for matched suite finish
• Framed top for connection to Griddle
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with two
adjustable feet at front and two rollers at rear
• Fully modular framed stand shelf with 0.9mm 304 stainless
steel finish
• Quick assembly design
Controls
• 50-300°C thermostat
• Single temperature control zone
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
• Indicator lights for power and heating
• Over-temperature safety cut-out
Cleaning and Servicing
• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove
cleaning traps
• Control service through front of unit
EP514-LS
