D91_M100_MX_100420 17.05.2010 12:15 Uhr Seite 1
Probedruck
C M Y CM MY CY CMY K
1.
2.
1005
3.
2.
1.
2.
1.
3.
1. 2.
2.
1.
1 min
8
ref. 460 140
a
c
b
d
90 sec
. . . . . ~ 3 kg
. . . . . max. 19 bar
. . . . . 220 - 240 V, 50 Hz, max. 1260 W
. . . . . 1 l
25.2 cm 29.1 cm16.6 cm
. . . . .
. . . . . 5
o
C ... 45
o
C
20
0 1200
300
18
36
0
dHfH
10 600
a
c
d
e
b
OK
Instruction Manual
Please read this Instruction Manual and the safety instructions before operating the appliance!
1
Fill tankRemove foil Place a container Plug mains +
switch ON
First starting or after a longer period of non-use
Fast flashing (2 x per sec):
Emptying, Descaling
Irregular interval blinking:
Send machine to repair
Lights up:
READY
Slowly flashing(1 x per sec):
Preheating, coffee, rinsing
Open
(1.)
and hold (2.)
Machine switches
off automatically
and is
blocked for 30 min
Let water run through
Rinse
When
READY:
Switch off
No water see:
6
Schliessen
Close
Before longer period of non-use, for frost protection, repair:
Empty system
When necessary:
Clean
5
Daily: before the 1st coffee
Rinse and
empty tank
Damped cloth,
cleaning agent mild
abrasive
solvent
containing
dish
washer
Fill with fresh water
8b
Carefully read safety instructions on
decalcifier package.
Decalcifier is aggressive to surface of casing.
Empty drip tray and
capsule container
Remove capsule
Preparation
Rinse machine, see 1
Water hardness Descale after
Fill in descaling kit
fluid and 0.5 l water
1. Lift lever 2. insert filter
3. close lever
Place a recipient
Rinse
Rinse machine, see 1Empty, rinse, clean and fill tankRemove filter
Descaling
Press simultaneously
for 3 seconds
Let decalcifier run through 2 times
Refill descaling solution
one time back into tank
Vinegar: Danger of damage
OFF
Descaling
7
Troubleshooting
No indication
Check mains: plug, voltage, fuse. In case of problems
call NESPRESSO Club
CloseWater comes
Venting
1. Open + 2. hold
Water tank empty –> fill water tank
No coffee,
no water
when rinsing
Machine blocked –> point 6
Descale, if necessary –> point 7
1
2
3
4
Coffee not hot enough Preheat cup, descale if necessary
Capsule area leaking
(water in capsule container)
Position capsule correctly.
If leakage: call NESPRESSO Club
Irregular interval blinking Send machine to repair or call NESPRESSO Club
Optional Accessory
NESPRESSO descaling kit
Specifications
Switch ON READYHeating up
3
Espresso Lungo
Preheat espresso cup: 1 cup of water
Eject capsule (drops into capsule container)
Insert
capsule
Flow speed
depends on
coffee variety
Coffee button
Drip grid
**
Drip tray
**
Capsule container for 12 – 14 capsules
**
Button ON/OFF
Coffee outlet
Lever
Water tank
**
**
Spare parts
After the last coffee:
Daily
4
Empty capsule
container + drip tray Switch off
Press
hold
and press 3 x
2
Start Stop Start Stop
Start
Stop
Start
Stop
Start Stop
If leakage
see:
8d
FOR UK AND REPUBLIC OF IRELAND ONLY
WARNING: Always replace the fuse cover of the fitted plug, never use the plug with the fuse cover omitted.
If a replacement fuse cover is required, ensure it is the same as the one visible on the pin face of the plug
(i.e. RED or ORANGE).
Fuse covers are available from: BBS Ltd
Po Box 110
Farnham Surrey GU104XL
Phone : 01252 727755
Use a 13 A fuse approved by ASTA to BS1362, marked thus
WARNING: a plug with a bared flexible cord is hazardous if engaged in a live socket. If the fitted plug
has been cut from the power supply cord, it should be destroyed and replaced with a three pin plug in
accordance with the following code: BLUE : neutral
BROWN : live
GREEN/YELLOW : earth
The wire which is coloured BLUE must be connected to the terminal in the plug which is marked with the
letter “N” or coloured BLUE or BLACK.
The wire which is coloured BROWN must be connected to the terminal in the plug which is marked with
the letter “L” or coloured BROWN or RED which is connected to the fuse.
The wire which is coloured GREEN/YELLOW should be connected to the terminal marked with the letter
“E”, or by the earth symbol or coloured GREEN or GREEN/YELLOW.
earth symbol
Safety precautions
This appliance may become a safety
hazard if these instructions and
safety precautions are ignored.
Keep this instruction manual
Emergency:
Immediately remove plug from power
socket.
The appliance is intended to prepare
beverages according to these
instructions.This appliance is intended to be
used in household and similar applications
such as: staff kitchen areas in shops, offices
and other working environments; farm houses;
by clients in hotels, motels and other residential
type environments; bed and breakfast type
environments. Do not use the appliance for
other than intended use. Remove plug from
from socket if not in use for long periods - holiday
etc.
Check that the voltage quoted on the
rating plate is the same as your
voltage. • Connect the appliance only to power
sockets with protective earth. The use of
incorrect connection voids warranty.
Place on a flat, stable heat-resistant
work surface away from water splashes
and any heat sources.
Do not use machine if it is not in
perfect working order, or if there is
any evidence of damage. In such cases
inform Nespresso Club immediately for
further assistance.
• Always close lever, never lift during
operation. - Do not put fingers into
capsule compartment and capsule shaft,
danger of injury. • Do not use appliance
without drip tray and drip grid.
• Keep appliance/cable out of reach of children.
Do not place power cord by hot parts
or sharp edges, etc. • Never touch cable
with wet hands. • Do not unplug by pulling
the cord.
• In case of damage, do not use the appliance.
In order to avoid danger have repairs and
replacement of power cord only by Nespresso
Club.
Do not open appliance and do not put
anything into openings. All operations
other than normal use, cleaning and care must
be performed by Nespresso Club.
This appliance has not been designed to
be used by persons (including children)
with physical, sensory or mental impairments
or who are lacking in experience or knowledge,
unless they have been given the necessary
supervision and prior instructions about how to
use this appliance by a person responsible for
their safety. Young children should be supervised
to ensure that they do not play with the appliance
Before cleaning/care, unplug the
appliance and let it cool down.
•
Never immerse either the whole machine,
power cord or plug, in water or any other
fluids.
Descaling:
7c) Do not lift lever during
descaling process. 7d) Rinse the water tank
and clean the machine to avoid any residual
descaling agent.
Packaging is made of recyclabe
materials
Unplug the machine and cut off the
power cord near housing. Dispose
of machine and cable at your public
disposal depot, or contact Customer
Services for further assistance.
ESSENZA M100
