Model 24RUFM Gas Donut Fryer
Model 24RUFM
Gas Donut Fryer
L10-015 Rev 6 (06/07)
STANDARD FEATURES & ACCESSORIES
Tank - stainless steel construction
Cabinet - stainless front, door, back and sides
Under Fryer Filter
Flush Hose
Solid state thermostat with melt cycle
Boil Out Capability
Standing Pilot
On/Off Switch
Indicating lights
Drainboard (also used as fryer cover)
Hinged wire mesh submerger screen wtih safety
grid handles
Filter Heater
Two nickle plated wire mesh screens with handles
Wire mesh tube screen
6” (15.2 cm) legs adjustable
One drain extension
One drain line clean-out rod
Heat deflector
Donut turner sticks (2)
Filter paper 11” x 13” envelope
Filter powder and fryer cleaner sample packets
AVAILABLE OPTIONS & ACCESSORIES
(At Additional Cost)
Electronic Ignition Cover
6” (15.2 cm) adjustable casters, front locking
Donut dropper bracket
(includes flanged bolt-down leg assembly)
Without filtration (UFM)
STANDARD SPECIFICATIONS
CONSTRUCTION
Tank constructed of durable stainless steel with an
extra smooth peened finish for easy cleaning.
Long-lasting, high-temperature alloy stainless
steel heat baffles are mounted in the heat
exchanger tubes to provide maximum heating
and combustion efficiency.
Standing pilot light design provides a ready flame
when heat is required.
1/2HP motor used to provide fast filtering
operation. Pumps up to 5 gallons per minute
(18.93 liters).
Filter pan heater
CONTROLS
Thermostat maintains selected temperature
automatically between 200°F (93°C) and 400°F
(204°C).
Integrated gas control valve acts as a manual and
pilot valve, automatic pilot valve, gas filter,
pressure regulator, and automatic main valve.
Gas control valve prevents gas flow to the main
burner until pilot is established and shuts off all
gas flow automatically if the pilot flame goes out.
Temperature limit switch safely shuts off all gas
flow if the fryer temperature exceeds the upper
limit.
OPERATIONS
Standing pilot and thermostat maintains
temperature automatically at the selected
temperature (200°F (93°C) and 400°F (204°C).
Bottom 1-1/4” (3.2 cm) full port drain valve for
quick draining.
Easy to remove under-fryer filter unit for fast
cleaning and paper replacement.
Filter piping integrated into the fryer for no-hassle
Shown with optional casters
