Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 •1509 Route 3A, Bow NH 03304, USA
(603) 225-6684 • Fax (603) 225-8472 • www.pitco.com
APPROVALS
CSA Certified
(AGA, CGA)
NSF Listed
MEA Approved
UL Listed
Patent Pending
Project
Item No.
Quantity
STANDARD ACCESSORIES
Food grid
Electric thermostat
Indicating lights
On/Off/Start switch
Drain line clean-out rod
Drain extension
Submerger
Drainboard
Cabinet - stainless steel front and door, galvanized
sides and back
AVAILABLE OPTIONS & ACCESSORIES
Stainless steel exterior Front work shelf
Stainless steel tank 480 volt service
Casters Covers
Drainboard
Left or right side work shelf
Submerger
Top holding shelf with removable tray.
STANDARD SPECIFICATIONS
CONSTRUCTION
Welded tank with an extra smooth peened finish
ensures easy cleaning.
Immersion type; sealed construction heating
elements with high temperature alloy stainless steel
sheath.
Element design makes cleaning easy.
Thermostat dial mounted on the front panel.
Provision for tie-in with fire protection systems.
CONTROLS
Temperature limit automatically shuts off all power
to the heating elements if the fryer temperature
exceeds the upper limit.
Three position switch (OFF/ON/START) for fryer
control.
Two position switch (MELT ON/MELT OFF) for melt
cycle control.
White power ON light.
Amber temperature light indicates when elements
are heating.
OPERATIONS
Thermostat maintains selected temperature
automatically at the selected temperature
(between 200°F (93°C) and 375°F (191°C-CE).
Front 1-1/2” (3.8 cm) drain, for quick draining.
Select fryer operating mode (on or melt cycle) from
the front control switch.
Model E24FF & E34FF - High Capacity Food and Fish Fryers
Model E24FF & E34FF
High Capacity Food and Fish Fryers
L10-030 Rev 7 (09/04)
