Pitco Frialator, Inc., P.O. Box 501, Concord, NH 03302-0501 x1509 Route 3A, Bow NH 03304, USA
Phone (603) 225-6684 x Fax (603) 225-8472 x www.pitco.com
L10-130 Rev 3 (02/07)
Model SG18
Tube Fired Gas Fryer
Project __________________________
Item number _____________________
Quantity _________________________
APPROVALS
CSA Certified
(AGA, CGA)
NSF Listed
MEA Approved
CE Certified
Australian Gas Assoc.
Certified (AuGA)
Patent Pending
Model SG18
STANDARD ACCESSORIES
Choice of basket options
Two nickel-plated, oblong, wire mesh baskets
One nickel-plated, square, wire mesh basket
One nickel-plated tube rack
One drain extension
One drain line clean-out rod
Fryer cleaner sample
Rear gas connection
Manual gas shutoff
1 1/4” (3.2 cm) full port drain valve
Built-in integrated flue deflector
Removable basket hanger for easy cleaning
9” (22.9 cm) adjustable legs
Cabinet - stainless steel front, door, and sides
Tank - mild steel
AVAILABLE OPTIONS & ACCESSORIES
Stainless steel tank
Stainless steel back
9” (22.9 cm) adjustable casters
Triple baskets
Covers
STANDARD SPECIFICATIONS
CONSTRUCTION
Welded tank with an extra smooth peened finish ensures
easy cleaning.
Long-lasting, high-temperature alloy stainless steel heat
baffles are mounted in the heat exchanger tubes to provide
maximum heating and combustion efficiency.
Standing pilot light design provides a ready flame when heat
is required.
Stainless steel front, door, side, and splashback.
Heavy duty 3/16” (.48 cm) door hinge.
CONTROLS
 Millivolt thermostat maintains selected temperature
automatically between 200qF (93qC) and 400qF (190qC-CE).
Integrated gas control valve acts as a manual and pilot valve,
automatic pilot valve, gas filter, pressure regulator, and
automatic main valve.
Gas control valve prevents gas flow to the main burner until
pilot is established and shuts off all gas flow automatically if
the pilot flame goes out.
Temperature limit switch safely shuts off all gas flow if the
fryer temperature exceeds the upper limit.
New Solstice burner/baffle design.***
-Increases cooking production.
-Lowers flue temperature.
-Improves working environment.
-Generates more production per BTU.
***Compared to previous models.
OPERATIONS
Front 1
1/4” (3.2 cm) full port drain for quick draining.
9” (22.9 cm) clearance allows for ease of cleaning.
