Project Quantity Item #
Model Specified: CSI Section 11400
SECTION
1-5
TRAULSEN
4401 BLUE MOUND RD. FT. WORTH, TX 76106
PHONE 1 (800) 825-8220 FAX-MKTG. 1 (817) 624-4302
Website: www.traulsen.com
Standard Product Features
• R-Series: Stainless Steel Exterior & Interior
• A-Series: Stainless Steel Exterior/Anodized Aluminum Interior
• INTELA-TRAUL
®
Microprocessor Control System
• Balanced, Self-Contained Refrigeration System Using R-134a
• Scroll Blower Type Evaporator Fan
• Biased Return Air Duct
• Full or Half Length Stainless Steel Doors With Locks
• Self-Closing Doors With Stay Open Feature At 120 Degrees
• Guaranteed For Life Cam-Lift Hinges
• Guaranteed For Life Horizontal Work Flow Door Handle
• Standard Door Hinging F & R: 132WP = Right, 232WP =
Left/Right, 332WP = Left/Right/Right (other hingings available)
• Automatically Activated Incandescent Lights
• Stainless Steel Breaker Caps
• Three Chrome Plated Adjustable Shelves Per Section,
Supported On Shelf Pins (installed at the factory)
• Automatic Non-Electric Condensate Evaporator
• Magnetic Snap-In Door Gaskets
• Gasket Protecting Metal Door Liner
• Controllable Anti-Condensate Door Perimeter Heaters
• Thermostatic Expansion Valve Metering Device
• Stainless Steel One-Piece Louver Assembly
• 9' Cord & Plug Attached
• Set of Four (4) 6" High Adjustable Stainless Steel Legs
• One Year Parts And Labor Warranty
• Two Year Control Warranty (parts and labor)
• Five Year Compressor Warranty
Options & Accessories
• Re-Hinging Feature For Door(s)
• No. 1 Type Tray Slides To Accommodate either (1) 18" x 26"
or (2) 14" x 18" Sheet Pans, Adjustable To 2" O.C.
• No. 2 Type Tray Slides To Accommodate (1) 18" x 26" Sheet
Pans, Adjustable To 2" O.C.
• No. 3 Type Tray Slides To Accommodate (2) 12" x 20" Steam
Table Pans, Adjustable To 2" O.C.
• No. 4 Type Tray Slides To Accommodate (1) 18" x 26" Sheet
Pans (chrome rod type, equips 1/2 section)
• Universal Type Tray Slides To Accommodate Either (1)
18" x 26" or (2) 14" x 18" Sheet Pans, or (2) 12" x 20" Steam
Table Pans, Adjustable To 4" O.C.
• Additional Chrome Plated Shelves
• Locking Hasps (padlocks supplied by others)
• Export 220/50/1 Voltage
• 208/115/60/1 Voltage In Lieu Of Standard 115/60/1
• Stainless Steel Shelves In Lieu of Standard Chrome Plated
• Kool Klad Exterior Laminate Decor
• Set of Four (4) 6" High Casters In Lieu of Legs
• Set of Four (4) 4-5/8" High Casters In Lieu of Legs
• 4-1/2" High Stainless Steel Base In Lieu of Legs
• 6" High Stainless Steel Kickplate (for use with standard legs)
• Prison/Correctional Facilities Options
• Remote Applications (see spec sheet 12-2 for more details)
• Clear Glass Door(s) In Place Of One Or More Solid Door(s)
• Two Year Service/Labor Warranty Available
"W-Width" Pass-Thru Refrigerator Models/
Self-Contained
Listed by Underwriters Laboratories Inc., to
U.S. and Canadian safety standards and
Listed by NSF International.
Approval: ___________________________________
Model RHT132WPUT-FHS
One, Two & Three Section Models, 32" Deep
1-Section Full Length Door Model RHT132WPUT-FHS
2-Section Full Length Door Model RHT232WPUT-FHS
3-Section Full Length Door Model RHT332WPUT-FHS
1-Section Half Length Door Model RHT132WPUT-HHS
2-Section Half Length Door Model RHT232WPUT-HHS
3-Section Half Length Door Model RHT332WPUT-HHS
R
SERIES
A
SERIES
1-Section Full Length Door Model AHT132WPUT-FHS
2-Section Full Length Door Model AHT232WPUT-FHS
3-Section Full Length Door Model AHT332WPUT-FHS
1-Section Half Length Door Model AHT132WPUT-HHS
2-Section Half Length Door Model AHT232WPUT-HHS
3-Section Half Length Door Model AHT332WPUT-HHS
(shown with optional casters)
INTELA-TRAUL
®
Equipped!
Stainless Exterior
& Interior
Stainless Exterior,
Anodized
Aluminum Interior
The R & A Series represent Traulsen's Top-of-the-Line product offering. The
“W-Width” pass-thru refrigerator models are all designed to offer
maximum interior storage capacity. Each is supplied standard with such high
quality features as balanced refrigeration systems, microprocessor controls,
communications ability and stainless steel exteriors. Additionally, they offer
the widest range of optional accessories to choose from, and can be
specified for use with many different applications, including: Foodservice,
Correctional, Institutional, Export, etc.
