Varimixer W20P Mixer User Manual



Specifications
Standard Features
W20P
Models
W20P Food Mixer
W20P Food Mixer
Project
Item
Quantity
CSI Section 11400
Approval
Date
Options &
Accessories
Powerful 1 hp motor with cord and
plug
Overload protection and no voltage
release
UL and NSF Listed
Neoprene feet to minimize walking,
rusting or counter damage
Provisions for bolting to counter or
table
Permanently lubricated planetary
head
15-minute timer
Stainless steel 20-qt. bowl and
stainless steel dough hook
12-qt. bowl and stainless steel
dough hook
Mixer table with or with-
out casters (see pictures)
Dimensions
18”W x 24” D x 22” H)
5489 Campus Drive
Shreveport, LA 71129 USA
Tel: 318-219-7051
Tel: 1-800-222-1138
Fax: 318-635-3131
E-mail: mix@varimixer.com
www.varimixer.com
Bulletin No. W20P 09/07
The Varimixer W20P is a rugged
20-Qt. mixer designed specifically
for mixing pretzel or pizza dough.
A powerful 1 horsepower motor
with thermal overload protection
guarantees peak performance
to mix the stiffest dough. The
tough stainless steel hook kneads
dough downward in hand-like
fashion to produce a smooth silky
dough that will not climb up the
hook. Dough removal from the
stainless steel bowl is clean and
easy.
The W20P single speed transmis-
sion is preset at an ideal 90 RPM
to assure consistent mixing by
even the most inexperienced
operator. Easy-to-use Start/
Stop buttons and a Timer are
front mounted for efficiency and
convenience.
A 6’ 115-volt cord and plug set
is included. The mixer base is
predrilled and bolts are provided
for securing the mixer to a work
surface. An optional 22-inch high
table raises the mixer to optimum
working height.
The W20P is Listed by NSF and
UL.
