Use & Care Manual
9
Burner Use Suggestions
Use the right front, right rear or left rear burners for
simmering, or for cooking smaller quantities of food
requiring small cookware. Use the left front POWER
Burner for bringing liquids to a rapid boil, cooking
large quantities of food, or for deep-fat frying requiring
large cookware.
The Burner Flames
Turn each burner on. Flames should be blue in color
with no trace of yellow. The burner flames should not
flutter or blow away from the burner. The inner cone of
the flame should be between 1/2" and 3/4" long.
Super Sealed Surface Burners
IMPORTANT: Do not obstruct the flow of combustion
and ventilation air around the burner grate edges.
Burner cap and gas spreader
Always keep the burner cap and gas spreader in
place when using a surface burner. A clean burner
cap and spreader will help prevent poor ignition and
uneven flames. Always clean the part after a spillover
and routinely remove and clean according to the
"General Cleaning" section.
Burner base and injector
Gas must flow freely throughout the injector orifice to
light properly. Keep this area free of soil and do not
allow spills, food, cleaning agents or any other
material to enter the injector orifice opening.
Protect it during cleaning.
Be sure when lighting the burner:
x Gas spreader pin is properly aligned with burner
base slot.
x Cap pin is properly aligned with gas spreader slot.
Burner ports
Check burner flames occasionally. A good flame is
blue in color, not yellow.
Keep this area free of soil and do not allow spills,
food, cleaning agents or any other material to enter
the burner ports.
To Clean gas burner:
IMPORTANT: Before cleaning, make sure all controls
are off and the cooktop is cool.
1. Remove the burner cap from the burner base and
clean according to cleaning section.
2. Remove the burner spreader.
Clean the gas tube opening and burner port
according to cleaning section.
3. Clean the burner base with a damp cloth (keep
the gas injector area free of cleaning agents and
any other material from entering the injector
orifice).
4. Replace the burner spreader and cap, making
sure the alignment pins are properly aligned with
the slots.
5. Turn on the burner.
If the burner does not light, check cap and
spreader alignment. If the burner still does not
light, do not service the gas burner yourself.
Contact a trained repair specialist.
COOKTOP
BURNER
-1/2” to 3/4”
Burner flames
