Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
A2780
ISO9001
Vulcan-Hart
Co.
F-32920 (10-07)
2XG45DF Shown with Food Warmer (Accessory)
2XGFGAS KLEENSCREEN PLUS® FILTRATION SYSTEM
STANDARD FEATURES
2XG45F filter system accommodates:
- One 45-50 lbs. capacity tank per fryer battery and one
Frymate Dump Station.
2XG65F filter system accommodates:
- One 65-70 lbs. capacity tank per fryer battery and one
Frymate Dump Station.
2XG85F filter system accommodates:
- One 85-90 lbs. capacity tank per fryer battery and one
Frymate Dump Station.
Choose from Millivolt (M), Solid State (D), or Computer (C)
Controls.
Drain valve interlock switch - available on (D) and (C) controls.
6" Casters adjustable - 2 locking, 2 non-locking.
Electronic ignition on solid state (D) and computer (C)
control fryers.
Drawn (seamless) 18 gauge, #304 stainless steel
filter pan. 70 lbs. frying compound capacity on 2XG45F,
110 lbs. capacity on 2XG65F and 2XG85F.
Paperless stainless steel filter screen filters from 2
sides filter area = 270 sq. inches. Mircro Filtration
Fabric Envelope filter area = 350 square inches.
1
/3 H.P. motor and pump circulates frying compound at a rate
of 8.0 gallons per minute.
Patented solenoid activated one touch push button switch to
engage pump and motor (solid state (D) and computer (C)
controls models only).
Boil Out ByPass™ removes water and discards oil.
Tank brush, stainless steel crumb scoop and clean-out rod.
One year limited parts and labor warranty. 12 year replace-
ment tank part warranty.
SPECIFICATIONS:
Patented Built-in filter system, Vulcan-Hart Model No. 2XG (lb.
capacity - 45,65 or 85) (control type M, D, or C) F (add suffix F to
fryer battery model No., i.e. 2XG45DF). Fryer battery consists of
a fryer on the left and a Frymate dump station on the right with
a KleenScreen Plus® filter system underneath. Maximum of
one 45, 65, or 85 lbs. capacity tank with one Frymate Dump
Station per fryer battery. Filter vessel constructed of 18 gauge
#304 series stainless steel. The 2XG45F filter pan weighs only
12.2 lbs. and the filter pan for the 2XG65F and 2XG85F weighs
only 20.5 lbs.
1
/3 H.P. motor/ pump circulates frying compound
at the rate of 8 gallons per minute, activated by a patented
solenoid push button switch. Patented System provided stan-
dard with paperless stainless steel mesh filter screen. A com-
plimentary package of KleenScreen Plus® Fabric Envelopes
is also included. Standard equipment comes on casters, a
primary crumb catch basket, tank brush, scoop and clean-out
rod. Hands free oil return line connection. Drain valve interlock
switch turns fryer's burners off when drain valve is opened.
Requires 120 volt, 60 Hz, 1 phase power supply. CSA design
certified. NSF Listed.
ACCESSORIES
Stainless steel tank cover.
Micro-Filtration Fabric Envelopes - 6 filters/per package
6' High Temperature Discard Hose
Rear oil reclamation discard connection.
GR45F - Twin Basket Lifts
GR85F - Single and Twin Basket Lifts
Food Warmer - HL1000
Prison security packages
Flexible gas hose with quick disconnect and restraining
device. Consult price book for available sizes.
2XGF GAS FRYER / FRYMATE
KLEENSCREEN PLUS®
FILTRATION SYSTEM
REFERENCE MATERIALS
See 1GR45 Spec Sheet F-32630
See 1GR65 Spec Sheet F-32631
See 1GR85 Spec Sheet F-32632
See Frymate Spec Sheet F-32530
OPTIONS
Second year extended limited parts and labor warranty.
SPECIFY TYPE OF GAS: NATURAL OR PROPANE
SPECIFY ALTITUDE: NATURAL GAS ABOVE 2,000 FT.
PROPANE GAS ABOVE 3,500 FT.
