ZANUSSI
P R O F E S S I O N A L
304 AISI CENTRAL TYPE HOODS
MASTER - M line - 1400 mm
304 S/S LABYRINTH FILTER H=500 MM 4 6 6 8 10 10 12 14
304 S/S BLIND PANEL 400X500H MM 2 2 2 2 2
INCLUDED ACCESSORIES
Net weight - kg. 29 35 42 49 55 62 69 76
Air Capacity - mc/h 2200 2900 3600 4300 5000 5700 6400 7100
height 500 500 500 500 500 500 500 500
depth 1400 1400 1400 1400 1400 1400 1400 1400
width 1200 1600 2000 2400 2800 3200 3600 4000
External dimensions - mm
MC1412DT
642105
MC1416DT
642106
MC1420DT
642107
MC1424DT
642108
MC1428DT
642109
MC1432DT
642110
MC1436DT
642111
MC1440DT
642112
CHARACTERISTICS MODELS
TECHNICAL DATA
RANGE
COMPOSITION
A range of wall-mounted hoods used
for snack applications and on the
N700 and N900 Series cooking
units. Their particular profile and the
limited installation height makes
them suitable for use in places with
low ceilings. The range consists of
hoods with 8 different lengths (1200,
1600, 2000, 2400, 2800, 3200, 3600
and 4000 mm) and a depth of 1400
mm.
FUNCTIONAL AND
CONSTRUCTION
FEATURES
� Constructed entirely in 304 AISI
stainless steel.
� Labyrinth filters in 304 AISI
stainless steel easily removable for
cleaning. Labyrinth filters guarantee
constant filtration to avoid clogging
and protect against fire.
� Central drain pipe with drain hole
to transfer grease into a 304 AISI
container.
� External panels with upturned
edges to avoid injuries.
� Blind panels in 304 AISI stainless
steel for a correct exhaustion.
� The outlet holes are sized in order
to minimize drops in pressure.
� Pressure gauging for perfect
calibration.
� Condensate collection tray in 304
AISI stainless steel.
� Eyebolts and screw anchors for
ceiling installation.
� Prearranged for installation of
lighting.
