11
063-2400
Recirculating Pump Assembly
RH 5-AG-S
American Dish Service
Ref.
No.
Part No.
No.
Req.
Description
1 091-1001 1 Motor, 1 ½ HP
2 082-6301 1 Rear Housing
3 092-2001 1 Seal Assembly
4 082-6303 1 Impeller, 5-vane
5 089-6303 1 Gasket
6 082-6302 1 Front Housing (Pump Cover)
7 085-6323 1 Discharge Pipe Weldment, 5-AG-S
8 092-1144 1 Pipe Plug, 3/8”, SS
9 092-1002 1 Petcock 1/8”
10 092-1145 1 Pipe Plug, 1/8”, SS
11 098-1507 2 Bolt, HH, SS, 5/16-18 x 7/8”
N/S 098-1510 2 Bolt, 5/16-18 x 1 ¼”, HH, SS
12 098-2503 4 Washer, Copper 5/16”
13 098-1607 4 Bolt, 3/8-16 x 7/8” HH SS
14 085-6321 1 Pump Pipe, Suction
15 093-1039 2 Rubber Sleeve, Suction Tube Kit
16 098-9038 4 Clamp, Suction Tube Sleeve
17 085-6322 1 Suction Tube, 5-AG-S
18 098-1426 2 Bolt, ¼-20 x ¾”, HH, SS
19 085-6408 1 Motor Plate
20 098-2404 6 Washer, ¼”, SS
21 098-1434 1 Bolt, ¼-20 x 2”, HH, SS
22 098-2507 3 Locknut, ¼-20, SS
Rep. 088-1012 Pump Assembly Through Impeller
(Needs Gasket 089-6303)
