Unit Installation
Free Standing Units
To ensure not only the efficient operation of your unit but also your safety.
When installing your unit follow the steps as shown below:
Place your unit on a flat level surface that is strong enough to support the unit once it is
fully loaded.
Your unit is equipped with adjustable height leveling legs to accommodate any minimal
changes in the level of the surface on which it is installed.
Countertop / Table Top Units
When installing units that can be placed on countertops, keep the following in mind:
Surface (countertop) is flat, level, and strong enough to support the unit once it is fully
loaded.
Surface is wide enough to accommodate the unit without any overhang.
Surface is deep enough to accommodate the unit when the door is opened to 90º
Electrical Connection
This refrigerator should be properly grounded for your safety. The power cord of this
refrigerator is equipped with a three-prong plug which mates with standard three prong wall
outlets to minimize the possibility of electrical shock.
Do not under any circumstances cut or remove the third ground prong from the power cord
supplied.
Use of extension cords is not recommended.
This refrigerator requires a standard 115/120-volt, 60Hz electrical outlet with three-prong
ground.
The cord should be secured behind the refrigerator and not left exposed or dangling to
prevent accidental injury.
Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull
straight out from the receptacle.
Warning
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.
