JUNE 9, 2010 2 1200 SERIES
ASAP Distributor Required Stocking Parts
Doors Are Not Returnable
* Item Is Too Large For UPS
IMPORTANT: When ordering parts, please provide the model, gas type
and serial number of the oven. The identification plate is located on
the left side of the combustion compartment and, also, above the control
panel under the ledge.
BAKING COMPARTMENT
COMPONENTS-CONT'D.
Ref. Part
No. No. Description
3840 Retainer Ring, Door
3652 Hinge Assy, Door Link
11694 Door Washer (Set of 10)
9411 Trim Assy, Bottom S/S (Before 11/74)
* 8353 Steel Deck Assy.
* 35058 Ultra Rokite Deck Assy
8989 Bulb Guard Assy.
20762 Cover Assy., Insulation LH
20763 Cover Assy, Insulation RH
ELEMENTS
Ref. Part
No. No. Description
18956 Element, 208V
19527 Element, 208V "L" Shape
8914 Element, 220V
10229 Element, 220V "L" Shape
8915 Element, 240V
10230 Element., 240V "L" Shape
8918 Element, 480V
10240 Element, 480V "L" Shape
20569 Element Jumper, with low cold end junction
(used with 208, 230, 240V)
ELECTRICAL COMPONENTS
Ref. Part
No. No. Description
10013 Element Terminal Shield
11240 Terminal Block w/Screws Hi-V
10559 Transformer 480/240V to 120V
15549 Indicator Light 125V, Red Rect.
9086 Fuse, 2 AMP, Class G
11267 Fuseholder, Class G
20615 Bracket, Contactor 50AMP
9973 Switch & Knob, Heater
9053 Knob, only (for heater switch)
For ovens before 8/84
17469 Knob, only (for heater switch)
For ovens after 7/84
5279 Thermostat, KX-38-36 (140-550°)
5943 Dial, Centigrade (For 5279)
11224 Dial, Fahrenheit (For 5279)
9062 Thermostat, KX-268-24 (200-650°)
(Thermostat to 700° no longer available)
19262 Dial, Fahrenheit (For 9062)
9630 Dial, Centigrade (For 9062)
15956 Timer, 60 Min. Rhodes
16030 Knob, Black
20349 Buzzer & Terminals, 120V
16820 Dial, Timer 1HR Cook
20350 Buzzer & Terminals, 240V
11427 Timer, 6 HR
3574 Terminal Block 65AMP, 600V
11203 Circuit Breaker, 60AMP
90588 Contactor w/ Hardware
5147 Timer, 60 Min. Mechanical w/Bell
34483 Dial, Timer 60 Min. Mechanical
34484 Knob, Timer 60 Min. Mechanical
11324 Timer, 5 HR
BAKING COMPARTMENT
COMPONENTS
Ref. Part
No. No. Description
10233 Handle, Door 21" (After 7/77)
9038 Handle, Door 20" (Before 7/77)
8342 Arm Assy, Door LH Support
8343 Arm Assy, Door RH Support
8338 Hinge Pin, Door RH
NOTE: Hinge Pin, Door LH is a welded/non-
replaceable part.
