GETTING TO KNOW YOUR FOOD PROCESSING
CENTER
1. Safety Cover
2. Safety Cover Release Button
3. Main Unit
4. Pulse/Turbo Button
5. On/Off Speed Control
6. Spindle
7. Blender Jar
8. Measuring Cap (1 oz.)
9. Blender Lid
10. Food Pusher
11. Food Processor Lid
12. Food Processor Bowl
13. Main Chopping Blade
14. Double Chopping Blade
15. Chopping Blade Protective
Cover
16. Dough Blade
17. Blade Storage
18. Blade Storage Cover
19. Thin Shredding Blade
20. Thick Shredding Blade
21. Thin Slicing Blade
22. Thick Slicing Blade
23. Grating Blade
24. Blade Holder
25. French Fry Disc Assembly
26. Spatula
27. Citrus Juice Filter
28. Juice Reamer
29. Juice Extractor Pusher
30. Juice Extractor Filter
31. Juice Extractor Lid
32. Whisk Head
33. Whisk Beater
34. Whipper
Technical Specifications
Voltage: 120V., 60Hz.
Power: 800 Watts
Food Processor Capacity: 5 Cups (1.25 Liters)
Blender Capacity: 6 Cups (1.5 Liters)
3
Operating the Blender
Setting up:
1. CAUTION: Make sure that the unit is unplugged
from the power source and the the Speed
Control Dial is in the "Off" position before
inserting or removing any attachments and
before cleaning.
2. Place the food processor bowl onto the
processor body. (Fig. 19)
3. When fitted correctly, the handle will fit into the
slot at the base of the unit.
4. Place the food processor lid on the bowl and
lock in place by turning counter clockwise.
(Fig. 20) Make sure that NO ATTACHMENTS
are inside the food processor bowl when you
are using the blender.
5. Open the safety cover by pressing on the safety
cover release button. (Fig. 21)
6. Place the blender jar in the opening and turn
counter clockwise to lock in place. (Fig. 22)
7. WARNING: Never operate the blender without
the blender lid in place. When processing hot
ingredients, remove the measuring cap from the
blender lid to allow steam to escape. (Fig. 23)
8. Recommended speed level for blending is "2"
(high). When blending soft vegetables or fruits
start with level "1" (low) and then go to level "2"
(high). For hard vegetables or fruit always use
speed level "2" (high).
IMPORTANT: Do NOT load the blender with more
than 10 oz. (300 gr.) of hard vegetables at one
time. Do NOT operate continuously for more than
20 seconds at one time.
NOTE: You can crush 16 oz. (500 ml) of ice cubes
in the blender using the PULSE/TURBO button.
CAUTION: To prevent spilling (overflow) do NOT
operate the blender with than 4 cups (1000 ml) of
soft liquid (i.e. soup) at one time.
* Always operate the blender with the blender lid
in place.
* When blending hot liquids, always remove the
small measuring cap in the blender lid.
* Avoid contact with moving parts at all times.
* Keep hair, clothing as well as spatulas and
other kitchen utensils out of the blender jar while
in operation to reduce the risk of severe injury to
persons or damage to the blender. A spatula
may be used but ONLY
when the unit is not in
use.
Fig. 19
OPERATING INSTRUCTIONS
Fig. 20
Fig. 21
Fig. 22
Fig. 23
10
