ARCTIC AIR
“Finally, a cheap chest freezer even the health inspector can love.”
–Walter Broich, Founder
All six models are tested and certified to ANSI/NSF Standard 7 for pre-packaged foods. These
freezers are efficient to operate, fully warranted, and save you hundreds of dollars because, even
though they wear the NSF mark, they’re priced more like household chest freezers.
White, poly-coated steel interior
is bright, durable and easy to clean.
One epoxy-coated wire basket comes with all
models. Extra baskets available, see below for
ordering information.
Efficient, warm-wall condenser keeps the cabinet
exterior dry without using electric heaters.
Environmentally friendly 134A refrigerant.
Convenient temperature control,
7 setting adjustments.
White, textured steel instead of
stainless, cuts costs and fingerprints.
Four, easy-to-install, heavy duty
casters standard with all models.
Heavy-duty pop-out key lock standard for
safety and security. Key automatically ejects
to prevent being left in the lock.
Tested and certified to ANSI/NSF Standard 7 for
pre-packaged foods—even ice cream—since these
freezers will deliver temps down to -18°F.
Freezers come with NSF Certified Thermometer.
Two and a half inches of wall insulation make
these units some of the most energy-efficient in
the industry. At .0867cents/KWH, average
energy costs range from $32 a year for the
5 cu. ft. model to $70 for the 20 cu. ft. model.
Simple, manual defrost.Water drain
port makes defrosting easy and efficient.
Made in USA and comes with full warranty:
5 years on compressor, 1 year parts and labor.
Model #
CF05
CF07
CF09
CF13
CF15
CF20
External Dimensions
Width
(A)
27.0
35.0
41.0
42.75
48.0
61.25
Height
(B)
36.9
36.9
36.9
36.9
36.9
36.9
Depth
(C)
21.75
21.75
21.75
27.5
27.5
27.5
Internal Dimensions
Width
21.75
29.75
35.75
37.5
42.75
56.0
Height
29.1
29.1
29.1
29.1
29.1
29.1
Depth
16.5
16.5
16.5
22.25
22.25
22.25
Cubic Feet
5.0
7.2
8.8
12.8
14.8
19.7
H.P.
1/6
1/6
1/6
1/3
1/3
1/3
Temperature
Range
-4.8º to -17.7ºF
-3.0º to -15.9ºF
-2.4º to -17.2ºF
-6.3º to -18.0ºF
-5.2º to -17.9ºF
-5.7º to -17.3ºF
Shipping
Weight
123 lbs
139 lbs
157 lbs
161 lbs
170 lbs
220 lbs
Average Annual
Operating Cost
$32
$40
$42
$63
$62
$70
A
B
C
Extra basket kits available.
For 5, 7 and 9 cu. ft. models
(CF05, CF07 and CF09) order
basket model 216710100.
For 13, 15, and 20 cu. ft. models
(CF13, CF15, and CF20) order
basket model 216710200.
Products and specifications subject to change.
UL
Division of Broich Enterprises, Inc. 6440 City West Parkway Eden Prairie, MN 55344 952-941-2270 Fax: 952-941-3066
www.arcticairco.com
NSF Certified and Listed by UL. 115 Volt. 15 Amp recommended circuit. Grounded outlet required, GFI circuit not recommended.
Front
Side
The beauty of these chest freezers only starts with the price.
The payoff comes when the health inspector visits.
