Cleveland
™
P
roject ________________________________
Item __________________________________
Quantity _______________________________
F
CSI Section ____________________________
A
pproval _______________________________
D
ate __________________________________
1333 East 179 St.,
Cleveland, Ohio, U.S.A. 44110
Tel: 1-216-481-4900
Fax: 1-216-481-3782
Web Site: www.ClevelandRange.com
Email: Steam@ClevelandRange.com
CLASSIC CONVECTION STEAMERS
15 PSI BOILER BASE STYLE
MODELS:
42-CKGM-200
42-CKGM-300
Cleveland Standard Features
■■
Cooking Capacity for up to six 12˝ x 20˝ x 2
1
⁄
2
˝ deep Cafeteria Pans.
■
■
Pressureless cooking with forced convection steam, permitting
doors to be opened while cooking continues.
■■
Solid State Controls operate water level and safety functions.
■■
Each compartment is equipped with a 60 minute mechanical
timer, separate bypass switch for constant steaming and a cold
water condenser for superior cooking results.
■■
Instant Steam Standby Mode: Holds generator at steaming
temperature. Allows unit to start cooking instantly.
■■
Durable 14 Gauge Stainless Steel Construction:
For Compartment Door and Steam Cooking Cavity.
■■
Separate Main Power Switch for “On/Off”
■■
Exclusive Steam Cooking Distribution System:
The
exclusive
Convection Jets produce a high velocity convection steam without
fans. Coved Corner design in cooking compartment distributes heat
evenly and is easy to keep clean. Creased top & bottom enhance
drainage. Cold Water Condenser for each compartment maintains a
dry steam. Fully insulated cooking compartment for thermal efficiency.
Removable Stainless Steel Slide Racks for easy cleaning.
■■
Exclusive “Cool to the Touch” Compartment Door Design:
Free floating inner door with reversible door gasket provides an
air tight seal. Stainless Steel Slam/Latch Door Latch mechanism
provides greater reliability.
■■
Left Hand Door Hinging: Compartment Doors hinged left,
controls on the right.
■■
Modular Cabinet Base with Hinged Door.
■■
High Efficiency Gas Steam Generator with Electronic Spark
Ignition and Automatic Water Fill on start up.
■■
Automatic Generator Drain at shutdown: Large
3
⁄
4
˝ drain valve
contains a “Water Jet” Spray Rinse Cleaning Cycle to keep drain clear.
■■
Automatic Water Level Control System with Low Water
Power Cut-Off.
■■
Steam generator equipped with High Limit Pressure Safety Switch,
15 psi Safety Valve, and Steam Generator Pressure Gauge.
■■
NSF Certified 6˝ Stainless Steel Legs with adjustable
flanged feet for a one inch level adjustment.
■■
Gas Pressure Regulator and Control Valve.
■■
Standard Voltage for Control: 115 volts, 60 Hz, single phase.
■■
Table Top includes 2˝ deep Drain Trough with
3
⁄4˝ Drain and
Grate
■■
6 gallon Tilting Kettle made of type 304 Stainless Steel,
2
⁄
3
jacketed
Kettle includes:
■■
Trunnion mounted Steam Control Valve
■■
50 psi Kettle Steam Jacket Rating
■■
Lift Off Cover
■■
Double Pantry Faucet with Swing Spout
Options & Accessories
❐ Right Hand Door Hinging, Controls and Kettles on the Left (DHR)
Shall be Two Compartments, CLEVELAND Convection Steamer, plus one 6
gallon Direct Steam, tilting, kettle, Model 42-CKGM- _____ , Gas-fired Steam
Generator, NickelGuard, _____ M BTU. Solid State Controls operate timing,
water level and safety functions. Steam Generator with Automatic Water Fill
on start-up, Automatic Blowdown with additional Manual Drain Valve and
Electronic Spark Ignition. For each cooking compartment: 60 minute
Mechanical Timer, Manual Operation Mode and Cold Water Condenser. Type
304 Stainless Steel cooking compartment.
❐ Electronic Timer with Compensating Load Feature (ETC)
❐ ON/OFF Steam Switch only for compartment controls (MC)
❐ Compartment Door Steam Shut Off Switch (SCS)
❐ Cafeteria pans in depths of 1˝, 2
1
⁄2˝, 4˝ and 6˝
❐ Power Take Off Kit (GPTO), Kettle Interconnecting Kit (IMK)
❐ Correctional Packages
❐ Stainless Steel Base Frame (FSS)
❐ Stainless Steel Insulated Flue Cover (SSF)
❐ Quick Disconnect for gas line (QDC)
❐ Type 316 Stainless Steel Liner for high acid products (316-6G)
❐ Secondary Low Water Cut-Off, factory installed (CALG)
(Required for AZ. AR. CA. CO. CT. DE. FL. GA. HI. IL. IA. KS. MD. MA. MI. MN. MT.
NE. NV. NM. NC. OK. OR. PR. RI. TN. UT. VA. WA. WV., Buffalo, NY, Wash. DC)
❐ Boiler Descaling Pump Kit (107142)
❐ Water Filters
❐ Rear Gas Connection (RGT)
❐
Compartment Door Steam Shut Off Switch
Short Form Specifications
Shown with optional
Electronic Timer
Cleveland Classic Series
TWO COMPARTMENT, PRESSURELESS, PLUS ONE 6 GALLON KETTLE,
200, 300M BTU GAS FIRED STEAM GENERATOR
42” WIDE CABINET BASE DESIGN, with NICKELGUARD™
CONVECTION
STEAMERS
1
0
0
%
5
Y
e
a
r
B
o
i
l
e
r
W
a
r
r
a
n
t
y
N
i
c
k
e
l
G
u
a
r
d
™
SECT. III PAGE 19
1007
