REFRIGERATOR FEATURES
Your model may have some or all of these features. Features that
can be purchased separately as product accessories are labeled
with the word “Accessory.” Not all accessories will fit all models.
If you are interested in purchasing one of the accessories, please
call the toll-free number on the cover or in the "Assistance or
Service" section.
Refrigerator Shelves
The shelves in your refrigerator are adjustable to meet your
individual storage needs. Your model may have glass or wire
shelves.
Storing similar food items together in your refrigerator and
adjusting the shelves to fit different heights of items will make
finding the exact item you want easier. It will also reduce the
amount of time the refrigerator door is open, and save energy.
Slide-out Shelves (on some models)
■ To slide out shelf, carefully pull front of shelf toward you.
■ To slide in shelf, push shelf in until it stops.
To remove and replace a shelf in a metal frame:
1.
Pull the shelf forward to the stop.
2.
Tilt the front of the shelf up and lift it slightly as you pull the
shelf from the frame.
3.
Replace the shelf by guiding it back into the slots on the
frame and pushing the shelf in past the stop.
Shelves and Shelf Frames
To remove and replace a shelf/frame:
1.
Remove the shelf/frame by tilting it up at the front and lifting it
out of the shelf supports.
2.
Replace the shelf/frame by guiding the rear shelf hooks into
the shelf supports. Tilt the front of the shelf up until rear shelf
hooks drop into the shelf supports.
3.
Lower the front of the shelf and check to make sure that the
shelf is securely in position.
Lateral Adjustable Shelf
(on some models)
To slide the shelf from side to side:
1.
Lift up on the front of shelf and slide to the desired location.
2.
Lower shelf to the level position.
NOTE:
You do not have to remove small items from the shelf
before moving it from side to side. You may need to remove
larger items.
To remove the shelf:
NOTE:
The shelf is heavy and must be removed using both
hands.
1.
Hold the back of the shelf with one hand.
2.
Lift the front of the shelf with the other hand to a 45° angle
and lower it slightly to release it from the upper channel of the
track. Pull the shelf straight out.
REFRIGERATOR section
too cold
■ Controls not set correctly for your
conditions
■ Blocked air stream
Turn
REFRIGERATOR
Control or
TEMPERATURE
Control to next
lower number, wait
24 hours, then re-
check
Move items out of
air stream
FREEZER section too cold
■ Controls not set correctly for your
conditions
■ Blocked air stream
Turn FREEZER
Control or
TEMPERATURE
Control to next
lower number, wait
24 hours, then re-
check
Move items out of
air stream
CONDITION/REASON:
RECOMMENDED
ADJUSTMENT:
Important information to know about glass shelves
and covers:
Do not clean glass shelves or covers with warm water when
they are cold. Shelves and covers may break if exposed to
sudden temperature changes or impact, such as bumping.
For your protection, tempered glass is designed to shatter
into many small, pebble-size pieces. This is normal. Glass
shelves and covers are heavy. Use special care when re-
moving them to avoid impact from dropping.
