Burners: The cooktop’s flame-less ignition system
generates a spark that lights the burner when you
turn the knob to HIGH. See the diagrams on the
right for the size and location of the different burner
types.
Long Life Grates: The porcelain coated cast iron
grates support the cooking utensils during cooking.
They are removable to allow the area below and
around the burners to be cleaned easily. The size
and location of each grate depends on the model of
the cooktop.
Spill Trays: The spill trays catch any food that falls
through the cooktop grates.
Burner Control Knobs: Use the knobs to turn on
the burners and adjust the flame size. An indicator
next to each knob lights when the burner control is
on.
Trim Rings: Located behind each knob. They pre-
vent liquids from getting into the cooktop’s internal
parts.
Special Cooktop Features
Perma-Flame™: The Perma-Flame instant
re-ignition feature automatically re-lights a burner
quickly if it goes out. With Perma-Flame, your cook-
ing experience is uninterrupted because the flame is
re-ignited at the same level as when it went out.
Smart Flame™ Technology: All burners are
equipped with Dacor’s Smart Flame technology. It
reduces the temperature under the fingers of the
porcelain-coated cast iron grates. Smart-Flame
extends grate life and protects the finish.
SimmerSear™ Burners: Dacor’s exclusive preci-
sion burner control system. SimmerSear burners
have a wider range of heat settings than the stan-
dard burners. The wider range allows you precise
heat control from simmer to sear (high).
Parts of the Cooktop
Getting to Know Your Cooktop
Model DRT304S - 4 burners
Model DRT366S - 6 burners
Burner Locations
A Standard Burner: 1300 - 9500 BTU
B Standard Burner: 1700 - 15000 BTU
C SimmerSear Burner: 800 - 18000 BTU
Burner
control knob
Burner
Grate
Trim ring
Spill tray
Model DRT366S
shown
