PLANNING
GUIDE
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
Specifications are subject to change without notice.
See installation instructions for additional details.
7.12
30”, 36”, 42”, 48”, 54” Wide
Hoods
2/3
WEIGHT SPECIFICATIONS
Models Weight
EH3012, MH3012 48 lbs. (22 kg)
EH3018, MH3018,
EH3612, MH3612
53 lbs. (24 kg)
EH3618, MH3618 57 lbs. (26 kg)
EH4212 55 lbs. (25 kg)
EH4218 60 lbs. (27 kg)
EH4812, MH4812 70 lbs. (32 kg)
EH4818, MH4818 77 lbs. (35 kg)
EH5418 84 lbs. (38 kg)
All Models
Fan Speeds 4
Filters Mesh type, dishwasher safe
Exhaust(s) 8-inch
Total Connect
Load
120 Vac, 60 Hz, 9 Amp MAX (10.0 Amp
MAX surge)
Lights 120 Vac, 75 W halogen
Circuit
Requirement
120 Vac, 15 Amp dedicated, grounded
circuit
Model Specific
MODEL NUMBER
EH48, EHR48,
MH48, EH54
EH42, EHR42
EH30, EHR30,
MH30, EH36,
EHR36, MH36
Lights 3 2 2
Filters 3 3 2
Exhaust
Outputs
2 1 1
Fan*
Rating
1200 CFM 600 CFM 600 CFM
* Does not apply to EHR Series
GENERAL SPECIFICATIONS
Revised
04/28/08
EH, EHR & MH Wall Mount
Range Hoods
WEIGHT SPECIFICATIONS
Model Weight
EHR3012 39 lbs. (18 kg)
EHR3018, EHR3612 44 lbs. (20 kg)
EHR3618 48 lbs. (22 kg)
EHR4212 46 lbs. (21 kg)
EHR4218 51 lbs. (23 kg)
EHR4812 52 lbs. (24 kg)
EHR4818 59 lbs. (27 kg)
EHR5418 66.4 lbs. (30 kg)
