EARTHING INSTRUCTIONS
This appliance must be earthed. In the event of an electrical short circuit, earthing reduces the risk of electric shock by
providing an escape wire for the electric current. This appliance is equipped with a cord having a earthing wire with a
earthing plug. The plug must be plugged into an outlet that is properly installed and earthed.
WARNING: Improper use of the earthing plug can result in a risk of electric shock. Consult a qualified
electrician or serviceman if the earthing instructions are not completely understood, or if doubt
exists as to whether the appliance is properly earthed. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade earthing plug, and a 3-slot
receptacle that will accept the plug on the appliance. The marked rating of the extension cord
should be equal to or greater than the electrical rating of the appliance.
INSTALLATION
Steady, flat location
This oven should be set on a steady, flat surface. This oven is designed for counter top use only.
Leave space behind and side
All air vents should be kept a clearance. If all vents are covered during operation, the oven may overheat and,
eventually, oven failure.
Away from radio and TV sets
Poor television reception and radio interference may result if the oven is located close to
a TV, Radio antenna, feeder and so on.
Position the oven as far from them as possible.
Away from heating appliance and water taps
Keep the oven away from hot air, steam or splash when choosing a place to position it, or the insulation might be
adversely affected and breakdowns occur.
Power supply
• Check your local power source. This oven requires a current of approximately 11 amperes, 230V 50Hz.
• Power supply cord is about 0.8 meters long.
• The voltage used must be the same as specified on this oven. Using a higher voltage may result in a fire or other
accident causing oven damage. Using low voltage will cause slow cooking. We are not responsible for damage
resulting from use of this oven with a voltage of ampere fuse other than those specified.
• If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Examine the oven after unpacking for any damage such as:
A misaligned door, Broken door, A dent in cavity. If any of the above are visible, DO NOT INSTALL, and notify
dealer immediately.
Do not operate the oven if it is colder than room temperature.
(This may occur during delivery in cold weather.) Allow the oven to become room temperature before operating.
The minimum height of free space necessary above the top surface of the oven is 100mm.
1
2
3
4
5
6
7
8
POWER SUPPLY 230V~50Hz, SINGLE PHASE WITH EARTHING
POWER
MICROWAVE 1200 W
CONSUMPTION
GRILL 1050 W
COMBINATION 2200 W
MICROWAVE ENERGY OUTPUT 800W
MICROWAVE FREQUENCY 2450MHz
OUTSIDE DIMENSIONS (WXHXD) 465X279X360mm
CAVITY DIMENSIONS (WXHXD) 290X220X306mm
NET WEIGHT APPROX. 13.7Kg
TIMER 59 min. 90 sec.
POWER SELECTIONS 10 LEVELS
CAVITY VOLUME 0.7 Cu.Ft.
* Specifications are subject to change without notice.
SPECIFICATIONS
IMPORTANT
The wires in this mains lead are coloured in accordance with the following code.
Green-and-yellow : Earth
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured
markings identifying the terminals in your plug, proceed as follows:
The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked
with the letter ‘E’ or by the earth symbol or green-and-yellow. The wire which is coloured blue must be
connected to the terminal which is marked with the letter 'N' or coloured black.
The wire which is coloured brown must be connected to the terminal which is marked with the letter ‘L’ or
coloured red.
WARNING: This appliance must be earthed.
