OPERATING INSTRUCTIONS
1) Pre-Rinse Light: Illuminates during Pre-Rinse
Cycle.
2) Wash Light: Illuminates during Wash Cycle.
3) Rinse Light: Illuminates during Rinse Cycle.
4) Drying Light: Illuminates during Drying period.
5) Door Handle: Pull to open the door.
6) START/PAUSE Button: Press this button to start
or pause dishwasher; light will illuminate when
starting.
7)Wash Program Selector: Turn the knob clockwise
to select wash cycles.
8) ON/OFF Button: To turn on/off the power supply.
Note: This model has a “Program Memory” function;
Cutton off power supply during washing will not reset
the current wash program. To cancel a program see
“Cancelling or Modifying a Wash Cycle Setting” pg. 7.
9) Power Light: Illuminates when ON/OFF button is
pressed.
10) Salt Aid Warning Light: Illuminates when
softener dispenser needs refilling.
11) Rinse Aid Warning Light: Illuminates when rinse
aid dispenser needs refilling.
9
8
7
6
5
4
2 10
1
3 11
3
WASH CYCLES
Cycle Name Type Description Detergent
(pre/main)
INTENSIVE
Intensive Wash 4/20 gr.
NORMAL
Normal wash 4/20 gr.
ECONOMY
Light Wash
For lightly soiled loads, such as plates, glasses, bowls and
lightly soiled pans.
20 gr.
RINSE
Rinse For dishes that need to be rinsed and dried only.
RAPID
WASH
Glassware For lightly soiled loads, such as glasses, crystal and fine
china.
15 gr.
SOAK
Soak Use to rinse the dishes that you plan to wash later that day. 15 gr.
For heavily soiled loads, such as pots, pans, casserole dishes
and dishes with dried food.
For normally soiled loads, such as pots, plates, glasses,
bowls, and lightly soiled pans. Standard daily cycle.
