DOOR REVERSAL
INSTRUCTIONS
1) To access the lower hinge
assembly, tilt back the freezer
cabinet or lay the freezer on its
back. (Fig.A)
2) Remove both leveling legs
located at the front of the
cabinet.
3) Remove the screws holding
the lower hinge assembly to the
cabinet.
4) Remove the main door
assembly from the freezer
cabinet (lift door slightly and
pull downward).
5) Using a flat head
screwdriver, remove the main
door top hinge pin.(Fig.B)
6) Re-install the main door top
hinge pin on the opposite side of
the cabinet.
7a) Remove the door plug and
door bushing located on the top
of the main door.
7b) Interchange their positions
(eg.door plug right side, door
bushing left side).
8) Re-install main door
assembly on cabinet.
9) Remove door bushing
(bottom door) and install on
opposite side.
10) Re-install the lower hinge
assembly on the opposite side.
11) Make sure the door
assembly is properly aligned on
the cabinet before tightening
lower hinge screws.
12) Re-install both leveling legs.
The process is now complete.
Fig. A
Fig. B
2
CAUTION: To avoid personal injury to yourself and/or property, we recommend
someone assist you during the door reversal process.
OPERATION
To start the freezer, turn the temperature control to the position corresponding to the
desired cooling.
0 = No Cooling 1= Minimum Cooling
3, 4 = Medium Cooling MAX= Maximum Cooling
The freezer temperature will vary depending on the quantity of the food stored and
on the frequency with which the door is opened.
DEFROSTING
INSTRUCTIONS
IMPORTANT: Do not use an ice pick, knife or other
sharp-pointed tool to defrost freezer. Damage can
occur.
1) Turn temperature control to ‘0’(off) and unplug
power cord.
2) Remove all frozen food.Wrap frozen food in
several layers of newspaper and cover with a blanket.
Food will say frozen for several hours OR store
frozen food in a cooler, additional refrigerator-freezer
or in a cool area.
3) Place pans of hot water in freezer with door open
to speed melting. Directing air from an electric fan
into freezer will also help. Do not place fan in freezer.
4) Remove frost.
5) Wipe water from walls and bottom of freezer with
a towel or sponge.
6) Wash inside walls.
7) Rinse and dry thoroughly.
8) Replace all frozen food.
9) Plug in power cord and refer to “Operation.”
OPERATING INSTRUCTIONS
Defrost and clean your freezer when frost has built up to about 1 1/4”(6mm) thickness.
Complete defrosting and cleaning should be done at least once a year. In high humidity
areas, a freezer may need more frequent defrosting and cleaning.
To avoid vibration, the cabinet must be set level.This is accomplished by adjusting the (2)
front leveling legs located under the freezer cabinet.
