OPERATING INSTRUCTIONS
1) THERMOSTAT DIAL: For controlling the
temperature inside the freezer. Turns the motor on
as soon as the temperature rises above the desired
level.
2) REFRIGERATED SHELVES:3 full width
refrigerated shelves.
3) MAGNETIC GASKET: Tight fitting door seal
keeps all the cooling power locked inside. No hooks
or latches.
4) DOOR BINS (4)
5) DRIP TRAY
1
2
3
4
FEATURES
DOOR
REVERSAL
INSTRUCTIONS
CAUTION: To avoid personal injury to yourself and/or property,
we recommend someone assist you during the door reversal
process.
1) To access the lower hinge assembly, tilt back the freezer cabinet
or lay the freezer on its back. (Fig.A)
2) Remove both leveling legs located at the front of the cabinet.
3) Remove the screws holding the lower hinge assembly to the
cabinet.
4) Remove the main door assembly from the freezer cabinet (lift
door slightly and pull downward).
5) Using a flat head screwdriver, remove the main door top hinge
pin.(Fig.B)
6) Re-install the main door top hinge pin on the opposite side of
the cabinet.
7a) Remove the door plug and door bushing located on the top of
the main door.
7b) Interchange their positions (eg.door plug right side, door
bushing left side).
8) Re-install main door assembly on cabinet.
9) Remove door bushing (bottom door) and install on opposite
side.
10) Re-install the lower hinge assembly on the opposite side.
11) Make sure the door assembly is properly aligned on the
cabinet before tightening lower hinge screws.
12) Re-install both leveling legs. The process is now complete.
Fig. A
Fig. B
2
