DCS CT-365WT Cooktop User Manual



10
PRODUCT MEASUREMENT SPECIFICATIONS
Dimensions shown below are for product reference only. REFER TO THE PRODUCT INSTALLATION
GUIDE FOR CABINET PREPARATION AND CUTOUT SPECIFICATIONS.
36"
Top View
Front View
R Side View
21"
19-1/2"
5-1/2"
4"
34-1/2"
2-3/4"
2-7/8"
Grate (p/n 12268-01)(2 pcs)
Grate (p/n 12269-01)
Knob (p/n 14301)(5 pcs)
CT-365
‘D’ Burner Cap (p/n 12272)(1 pcs)
‘C’ Burner Cap
(p/n 12273)(4 pcs)
