air-o-convect
LPG Gas Hybrid
Convection Oven 201
air-o-convect
LPG Gas Hybrid Convection Oven 201
The company reserves the right to make modifications to the products
without prior notice. All information correct at time of printing.
2012.07.24
Front
Top
CWI = Cold Water inlet
D = Drain
DO = Overflow drain pipe
EI = Electrical connection
G = Gas connection
Side
Electric
Supply voltage:
269714(AOS201GCD2) 230 V/1N ph/50/60 Hz
Circuit Breaker required
Gas
ISO 7/1 gas connection diameter: 1" MNPT
LPG:
Pressure: 11" w.c. (27.4 mbar)
Heating elements: 136360 BTU (40 kW)
Total thermal load: 136360 BTU (40 kW)
Water:
Water inlet "CW" connection: 3/4"
Total hardness: 5-50 ppm
Pressure: 1.5-4.5 bar
Drain "D": 1"1/4
Electrolux recommends the use of treated water, based on
testing of specific water conditions.
Please refer to user manual for detailed water quality
information.
Installation:
Clearance: 5 cm rear and right hand sides.
Suggested clearance for service
access: 50 cm left hand side.
Capacity:
GN: 20 - 1/1 Gastronorm
Max load capacity: 100 kg
Key Information:
Net weight: 297 kg
Shipping weight: 322 kg
Shipping height: 1795 mm
Shipping width: 993 mm
Shipping depth: 957 mm
Shipping volume: 1.71 m³
