Under-Counter Wine Cooler
EI24WC65G S
High standards of quality at Electrolux Home Products, Inc. mean
we are constantly working to improve our products. We reserve the right
to change specifications or discontinue models without notice.
USA
•
250 Bobby Jones Expressway
•
Augusta, GA 30907
•
1-877-4electrolux (1-877-435-3287)
•
electroluxappliances.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
electroluxappliances.ca
EI24WC65G 04/08 © 2008 Electrolux Home Products, Inc. Printed in the U.S.A.
24
1
/8"
34
1
/4"
min.
24"
min.
90°
90°
Left
26
3
/4"
34"
Adjustable
to 35"
24
1
/4"
21
9
/16"
Top
2
7
/8"
Door in 90°
open position
47"
23
5
/8"
Front
Power cord
location (right
bottom rear)
2
3
/4"
3
5
/16"
23
13
/16"
Under-Counter Wine Cooler Specifications
•
Product Weight – 128 Lbs.
•
Voltage Rating –120V/60 Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 0.15kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @120 Volts = 6 Amps
•
Electrical cable supplied.
•
Always consult local and/or national electric codes.
•
Can be used freestanding, or built in under counter.
•
Does not require additional airspace for top, sides or rear when used
in built-in application. Increase unit dimensions by at least 1/4" for
recommended rough opening.
•
Front grille MUST remain unobstructed for proper ventilation.
•
Must be positioned on flat, level surface, capable of supporting entire
weight when fully loaded.
•
Leveling legs supplied to adjust height and level unit.
•
Do not position unit near any heat source to ensure optimum
performance.
•
Must be positioned to allow for 90° door swing, providing sliding
shelves with necessary clearance. (Door is field reversible for right- or
left-hand opening.)
•
When installing next to wall where handle may make contact, allow
3" clearance between opened door and wall.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
Field-Reversible Door Kit – (5303918374).
