Control Panel
Best results are obtained by using a low speed
for normal conditions and a high speed when
odours are more concentrated.
Turn the hood on a few minutes before you start
cooking, you will then get an under pressure in
the kitchen. The hood should be left on after
cooking for about 15 minutes or until all the
odours have disappeared. The control switches
are located on the unit’s front panel:
the light switch switches the hood lamp ON
and OFF;
ON/OFF Extractor fan switch - Push-button
1: used to turn the fan off and to set the fan to
speed 1.
Push-button 2: used to set the fan to speed 2.
Push-button 3: used to set the fan to speed 3.
Correct ventilation
If the cooker hood is to work correctly there must
be an under pressure in the kitchen. It is important
to keep the kitchen windows closed and have a
window in an adjacent room open.
Light switch
ON/OFF
Extractor fan switch -
Push-button 1
Push-button 2
Push-button 3
Fig. 3 - Control Panel
