Safety Instructions Operating Instructions Troubleshooting Tips Consumer SupportInstallation Instructions
Door Reversal
4 Cubic Foot Models
1. Remove the two screws at the back of
the top cover.
2. Remove the top cover by lifting the back
up about 2″and then sliding it forward.
3. Remove the small plug button on the
left side of the door top cap.
4. Remove the three screws on the upper
hinge (right side). Remove the hinge.
5. Remove the three screws at the left
hinge location on the top plate.
6. Remove the screw in the middle of the
top plate and remove the top plate.
7. Lift the door up and off the bottom
hinge (right side).
8. Tilt the refrigerator cabinet back to
remove the right leveling leg.
9. Remove the screws on the bottom
hinge (right side) and the left leveling
leg. Move the bottom hinge to the left
side and secure it with the screws and
leveling leg.
IMPORTANT: The left leg has a spacer that
must be moved to the right side leveling leg
when the door swing is reversed.
10. Screw the right leveling leg, with the
spacer in place, back in place on the
right side.
11. Position the door on the left bottom
hinge. With the magnetic gasket
holding the door in place, secure the
top hinge with screws.
12.
Make sure the door is aligned with the
refrigerator cabinet before continuing.
13. Replace the top plate and screws.
14. Slide the top cover back in place and
replace the two screws.
15. Put the plug button in the hole on the
right side of the door top cap.
Leveling legs
Bottom
hinge
Plug button
Spacer
Left hinge location
Upper
hinge
Top cover
Top
plate
Door
top cap
