For answers to your Monogram,
®
GE Profile
™
or
GE
®
appliance questions, visit our website at
ge.com or call GE Answer Center
®
service,
800.626.2000.
Specification Revised 6/09
210379
PSB48YGX
GE Profile
™
48" Built-In Side-By-Side Refrigerator with Dispenser
Total volume and shelf
area are calculated by
the Association of Home
Appliance Manufacturers’
standards.
Listed by
Underwriters
Laboratories
.250 + .750 = 1.000 Maximum Total Panel Thickness
3/4" Custom Panel Dimensions
For a more custom appearance, 3/4" framed custom panels may be installed on
trimmed models. The overlay panel is secured to a 1/4" finished backer panel.
The custom panel then slides into the trim. Please see installation instructions
for detailed information.
Custom Panel
Backer Panel
NOTE: Left-to-right offset is not always
equal to top-to-bottom offset.
1/4" Framed Panel Dimensions
If you choose to install framed panels, they must be cut to the dimensions
shown. The panels will slide into the frame on the door and grille.
IMPORTANT NOTE:
Maximum weight for Fresh Food panel is
70 pounds and 30 pounds total for Freezer
panels.
1/4"
Panel
Door
5/16"
Trim
Reveal
E
D
F
A
B
Grille Panel
C
Dispenser
Cutout
Freezer
Panel
Fresh Food
Panel
G
IMPORTANT NOTE:
Dispenser Trim
The refrigerator is supplied with factory installed
dispenser trim.
• If panel is less than 1/4" thick, a noticeable gap will
be created around the dispenser trim. Foam tape
may be applied on the door to improve the fit.
• If panel is more than 1/4" thick, the panel will not t
behind the trim.
1/4" Front Panel Dimensions (in inches)
A B C D E F G
48" Models 45-31/32 10-3/4 67-7/8 18-15/32 26-15/32 17-5/8 35-5/32
3/4"
Custom
Panel
1/4"
Backer
Panel
Door
3/4"
