6
STEP 3 LEVEL
• Use an adjustable wrench to turn the leveling legs
and raise or lower the product.
• Adjust carefully; the product should be level and
plumb with cabinetry, and should align with adjacent
toekick height.
STEP 5 SLIDE PRODUCT INTO
THE CUTOUT
• Carefully, slide the unit into the opening.
Be careful not to entangle power cord.
• Make certain that the door protrudes 1″ beyond
the surrounding cabinets.
• Check again to be sure the unit is level.
STEP 4 CONNECT POWER
• Connect power cord plug to a properly grounded
receptacle.
• Check to make sure power is on by opening the door
to see if interior light turns on.
STEP 6 INSTALL NAMEPLATE
• Follow instructions on the back page for installation
of the Monogram nameplate.
STEP 7 SET TEMPERATURE
CONTROLS
• The temperature controls are preset. Refer to
the Owner’s Manual for more information.
Allow 24 hours for temperature to stabilize.
Turn Right to Lower
Turn Left to Raise
If you skipped Step 2:
• Select the hinge cover marked “R” or “L”, depending
on door swing.
• Peel backing off the tape inside the decorative
hinge cover. Press and snap into position.
• Snap the screw hole cover into place on the
opposite side.
Installation Instructions
