Filter
Top Products
Crathco® Model # D25 Double Bowl
Premix Dispensers
Specifications D25 (115V/60Hz) D255 (230V/50Hz) D256 (230V/60Hz)
# Bowls 2 2 2
Bowl Capacity (per bowl) 5 gallons (18.9L) 5 gallons (18.9L) 5 gallons (18.9L)
Refrigeration 1/5 hp 1/5 hp 1/5 hp
Volts / Hz / Amps 115V / 60Hz / 5.5Amp 230V / 50Hz / 2.7Amp 230V / 60Hz / 2.7Amp
Dimensions
(H x W x D)
27 1/4” x 17 1/2” x 15”
(69cm x 44cm x 38 cm)
27 1/4” x 17 1/2” x 15”
(69 cm x 44 cm x 38 cm)
27 1/4” x 17 1/2” x 15”
(69 cm x 44 cm x 38 cm)
Ship Dimensions
(H x W x D)
Base: 16-1/4” x 20-3/4” x 13-1/2”
(41 cm x 53 cm x 34 cm)
Bowl: 22-1/2” x 15-1/2” x 8-1/2”
(57 cm x 39 cm x 22 cm)
Base: 16-1/4” x 20-3/4” x 13-1/2”
(41 cm x 53 cm x 34 cm)
Bowl: 22-1/2” x 15-1/2” x 8-1/2”
(57 cm x 39 cm x 22 cm)
Base: 16-1/4” x 20-3/4” x 13-1/2”
(41 cm x 53 cm x 34 cm)
Bowl: 22-1/2” x 15-1/2” x 8-1/2”
(57 cm x 39 cm x 22 cm)
Ship Weight (2 boxes)
77 lbs (base: 60, bowls: 17)
34.9 kg (base: 27, bowls: 8)
77 lbs (base: 60, bowls: 17)
34.9 kg (base: 27, bowls: 8)
77 lbs (base: 60, bowls: 17)
34.9 kg (base: 27, bowls: 8)
Cup Height 8 1/4” (20.5 cm) 8 1/4” (20.5 cm) 8 1/4” (20.5 cm)
Listings UL, NSF, CUL NSF, CE NSF, CE
Specifications
Whipper Models
1WD25 (115V/60Hz)
(2 bowls - 1 whipper)
2WD25 (115V/60Hz)
(2 bowls - 2 whippers)
1WD255 (230V/50Hz)
(2 bowls - 1 whipper)
2WD255 (230V/50Hz)
(2 bowls - 2 whippers)
Bowl Capacity (per bowl) 5 gallons (18.9L) 5 gallons (18.9L) 5 gallons (18.9L) 5 gallons (18.9L)
Refrigeration 1/5 hp 1/5 hp 1/5 hp 1/5 hp
Volts / Hz / Amps 115V / 60Hz / 6.1Amp 115V / 60Hz / 6.7Amp 230V / 50Hz / 3Amp 230V / 50Hz / 3.3Amp
Dimensions
(H x W x D)
29 3/4” x 17 1/2” x 15”
(76 cm x 44 cm x 38 cm)
29 3/4” x 17 1/2” x 15”
(76 cm x 44 cm x 38 cm)
29 3/4” x 17 1/2” x 15
(76 cm x 44 cm x 38 cm)
29 3/4” x 17 1/2” x 15
(76 cm x 44 cm x 38 cm)
Ship Dimensions
(H x W x D)
Base: 18-1/2” x 20-7/8” x 15-1/2”
(47 cm x 53 cm x 39 cm)
Bowl: 22-1/2” x 15-1/2” x 8-1/2”
(57 cm x 39 cm x 22 cm)
Base: 18-1/2” x 20-7/8” x 15-1/2”
(47 cm x 53 cm x 39 cm)
Bowl: 22-1/2” x 15-1/2” x 8-1/2”
(57 cm x 39 cm x 22 cm)
Base: 18-1/2” x 20-7/8” x 15-1/2”
(47 cm x 53 cm x 39 cm)
Bowl: 22-1/2” x 15-1/2” x 8-1/2”
(57 cm x 39 cm x 22 cm)
Base: 18-1/2” x 20-7/8” x 15-1/2”
(47 cm x 53 cm x 39 cm)
Bowl: 22-1/2” x 15-1/2” x 8-1/2”
(57 cm x 39 cm x 22 cm)
Ship Weight (2 boxes)
77 lbs (base:62, bowls:15)
35 kg (base:28, bowls:7)
78 lbs (base:63, bowls:15)
35.3 kg (base: 28.5, bowls: 6.8)
77 lbs (base:62, bowls:15)
35 kg (base:28, bowls:7)
78 lbs (base:63, bowls:15)
35.3 kg (base:28.5, bowls:6.8)
Cup Height 5 1/2” (14 cm) 5 1/2” (14 cm) 5 1/2” (14 cm) 5 1/2” (14 cm)
Listings UL, NSF, CUL UL, NSF, CUL NSF, CE NSF, CE
Tel (502) 425-4776 • Fax (502) 425-4664 • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: info@grindmaster.com
0307 Form # CC-275-05
© Grindmaster Corporation, 2002
PRINTED IN USA
17-1/2 [44]
15 [38]
11-1/8 [28]
27-1/4 [69]
Standard Options*
Side panels & drip tray -3 Stainless steel material (additional charge), -4 off-white high impact plastic (standard - no additional charge)
Valve cap (part# 2039) Improves sealing of valve when using pulpy products
Valve locking box (part# 2502)
(use w/ standard handle)
Secures the valve from dispensing during off-hours - not to be used with non-contact handle
Liquid Auto Fill (part# 90295) Ensures proper product and mixing consistency, maintains optimum product level in bowls, eliminates need for frequent manual mixing
Shipboard kit (part# 5925) Makes unit safer for installation aboard marine vessel; only available for use with agitator
Milk Fat Impellers Use with milk-based products, and/or products with heavy pulp
Condensation Control Direct and conceal condensation in high humidity or outdoor locations
Custom Options* (available with minimum purchase quantity)
Frosted Bowls 5 gal. (18.9L) Frosted surface simulates condensation while helping hide product residue and offering added UV protection.
Frosted Lid Lid with frosted surface for use with 5 gallon (18.9L) frosted bowls
Whippers (must be ordered when
ordering machine)
(see models in spec chart below)
Great for iced cappuccinos and iced coffee. Whips beverage upon dispensing to create a frothy top on drink.
* Additional cost applies
Specifications are subject to improvement or change without notice.
