Page 4 of 4 F7543 – Foodwaste Disposer Replacement Cone Adapters
As continued product improvement is a policy of Hobart, specications are subject to change without notice.
FOODWASTE DISPOSER
REPLACEMENT CONE ADAPTERS
F7543 (REV. 03/14) LITHO IN U.S.A. (H-01)
STAINLESS STEEL ADAPTER KIT DESCRIPTIONS
ADAPTER #ML-31167
Bolts directly to a Type #1 Cone.
ADAPTER #ML-31162,
#ML-31163, #ML31164 and
#ML-31165
Use an “O” Ring to seal around the
sleeve of a Type #4 Cone.
ADAPTER #ML-31166
Bolts directly to existing clamp ring of
Type #3 Cone. Reuse clamp ring and
screws already on the Cone.
ADAPTERS #ML-31159,
#ML-31160, #ML-31169,
#ML-31170 and #ML-31171
Clamp to ange of Type #2 or Type #3
Cones. Rubber splash guard between
solid ring and split ring. Use silicone seal
to make it permanent.
ADAPTER #ML-31168
Bolts directly to a Type #2 Cone.
ADAPTER #ML-31161
Retains a special seal which is
compressed against a Type #5 Cone.
NOTE: Sealastic or similiar silicone
gasket material should be used if
additional sealing is required when
adapting a new disposer to an existing
cone.
