Icemaker & Adaptor Hold-Down Kit Installation Instructions
© 2008, IMI Cornelius Inc. - 1 - Publication Number: 629096853INS
INSTALLATION INSTRUCTIONS
ICEMAKER AND ADAPTER HOLD-DOWN KIT P/N 629096853
F
OR FLAVOR FUSION / IDC UNITS ONLY
Instructions for Non-30 Inch Wide Icemaker – Flavor Fusion Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Instructions for 30 Inch Wide Icemakers – Flavor Fusion Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Instructions for Non-30 Inch Wide Icemaker – IDC Series Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Instructions for 30 Inch Wide Icemaker – IDC Series Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Parts Included in the Kit are Shown in Table 1:
Tools Needed:
• Power Drill
• 9/64 in. (.140 in.) Drill Bit
• #2 Phillips Head Screwdriver
INSTRUCTIONS FOR NON-30 INCH WIDE ICEMAKER – FLAVOR FUSION UNITS
WARNING: Failure to follow the installation instructions correctly may result in equipment damage
and/or personal injury.
The Parts shown in Table 2 are NOT Used for this Installation:
1. Remove the two top black side panel screws from both sides of the Flavor Fusion unit (See Figure 1) and
save the screws.
Table 1
Part No. Description Qty.
22127 Icemaker Rear Mounting Plate 2
50904 Silicone sealant 1 tube
620053922 Left Side Adapter Hold-Down Bracket 1
620053923 Right Side Adapter Hold-Down Bracket 1
620518916 Adaptor/Icemaker Side Hold-Down Plate (Flat) 2
620701601 #10-16 S.S. Sheetmetal Screws 12
Table 2
Part No. Description Qty.
620518916 Adaptor/Icemaker Side Hold-Down Plate (Flat) 2
Release Date: June 30, 2008 www.cornelius.com Revision: 1
