General Information
Page A2
How To Use This Manual
Cornelius provides this manual as an aid to the service technician in installation, operation, and
maintenance of the CCM/CCU Series (electro-mechanical) cube ice machines. If used properly
this manual can also assist the service technician to troubleshoot and diagnose most of the
problems that may occur with the machine.
The first two sections of this manual provide general information and maintenance information.
The remainder of the manual beginning with Section C provides troubleshooting and service
information. Section C contains flow charts called troubleshooting trees. Page C-1 provides
instructions on using the troubleshooting trees. Each troubleshooting tree is named to describe
a particular problem with the operation of the machine.
When following the troubleshooting trees, the service technician will be led through questions
and checks and end up with a probable solution. When using the troubleshooting trees, it is
important that the service technician understand the operation and adjustments of the
components being checked and the component suspected of malfunctioning. A detailed
description of the operation and adjustments of the components as well as other service
information is available in the pages that follow Section C.
Sections D, E, and F focus on a particular system in the ice machine: water distribution system,
refrigeration system, and it is important that these sections be used together with the
Troubleshooting Trees in Section C.
Most aspects of the CCM/CCU Series machines are covered in this manual, however, should
you encounter any conditions not addressed herein, please contact the Cornelius Technical
Service Department for assistance. You may also e-mail the Cornelius Technical Service
Department:
E-Mail: tech.service@Cornelius.com
Website : www.cornelius.com
Telephone Number
800-238-3600 All Departments
Any Service communication must include:
• Model Number
• Serial number
• A detailed explanation of the problem
Note the warning symbol where it appears in this manual.
It is an alert for important safety information on a hazard
that might cause serious injury.
Keep this manual for future reference.
The CCM/CCU Series Service Parts Manuals are available separately.
Cornelius products are not designed for outdoor installation.
